IRONHEAD XL

SEATS &
SISSY BARS

EXHAUST

CARBURETORS
& AIR FILTERS 0601-1376

ENGINE
0601-0846

TRANSMISSION
& DRIVELINE

GASKETS
& SEALS 25,4 MM (1”) NARROW
APE HANDLEBARS
•Feature a narrow center/ tapered
ELECTRICAL design for a great new look on
& LIGHTING narrow glide front ends
•High-quality steel tubing with 0601-0849
1
89 mm (3 /2”) on-center knurling
•Slotted and drilled for
HANDLEBARS,
internal wiring
CONTROLS & •Available in black or chrome finish
MIRRORS •Made in the U.S.A.
CHROME PART # BLACK PART # END RISE WIDTH CENTER WIDTH PULLBACK
1
1
0601‑1376 0601‑1375 30,5 cm (12”) 83 cm (32 /2”) 11 cm (4 /4”) 18 cm (7”)
1
CABLES 0601‑0847 0601‑0846 35,5 cm (14”) 83 cm (32 1 /2”) 11 cm (4 /4”) 18 cm (7”)
1
0601‑0849 0601‑0848 40,5 cm (16”) 83 cm (32 1 /2”) 11 cm (4 /4”) 18 cm (7”)

BRAKES
OIL TANKS,
FILTERS &
GAS TANKS 25,4 MM (1”) BEACH BARS DS-300237
•Get retro with these ‘40s style handlebars
•Constructed from high-quality steel tubing with a knurled center
DASHES •Highly polished, brilliantly chrome-plated
& GAUGES •Made in the U.S.A.
PART # DESCRIPTION END RISE WIDTH CENTER WIDTH PULLBACK
BIKINI BARS
CHASSIS, DS‑300248 Dimpled and drilled 11,5 cm (4,5”) 91 cm (36”) 20,5 cm (8”) 32,5 cm (12,75”)
SUSPENSION, DS‑300237 Dimpled 11,5 cm (4,5”) 91 cm (36”) 20,5 cm (8”) 32,5 cm (12,75”)
FENDERS
& WHEELS

FLOORBOARDS
& PEGS

HARDWARE
25,4 MM (1”) CHROME LONGHORN BARS
•Constructed of steel tubing with knurled center
•Similar in design to the Beach Bar
•Made in the U.S.A.
GENERAL PART # DESCRIPTION WIDTH CENTER WIDTH RISE PULLBACK
LONGHORN BARS
DS‑300239 Dimpled 99 cm (39”) 24 cm (9,5”) 19 cm (7,5”) 44 cm (17,25”)

662 ALL PART NUMBERS IN BLUE ARE NEW
