25,4 MM (1”) HANDLEBARS top
•When people think of quality handlebars, Flanders is at the top of the list pullback
•Over fifty years’ experience making the world’s finest handlebars TRANSMISSION
•All handlebars are made of seamless, cold-drawn steel tubing width & DRIVELINE
•Mandrel-bent for accuracy front
•Available in chrome and black rise
•Made in the U.S.A. GASKETS
1
NOTE: Standard handlebars have 89 mm (3 /2”) centered knurling; Springer & SEALS
handlebars have 12 cm (4 /4”) centered knurling. center width
3
STYLE RISE WIDTH CENTER WIDTH PULLBACK UNKNURLED NO DIMPLES KNURLED DIMPLED KNURLED DRILLED
25,4 MM (1”) CLASSIC BENDS, CHROME
#1 20,5 cm (8”) 90 cm (35,5”) 21,5 cm (8,5”) 23 cm (9”) - DS-300118 - ELECTRICAL
#2 18 cm (7”) 86 cm (34”) 21,5 cm (8,5”) 21,5 cm (8,5”) - DS-300131 - & LIGHTING
Original Ape Hanger 32 cm (12,5”) 88 cm (34,5”) 21,5 cm (8,5”) 25,5 cm (10”) DS-300117 DS-300114 DS-300214
Tall Ape Hanger 33 cm (13”) 89 cm (35”) 28 cm (11”) 26,7cm (10,5”) - DS-300113 DS-300215
Mini Ape Hanger 25,5 cm (10”) 87 cm (34,25”) 20,5 cm (8”) 25,5 cm (10”) DS-300146 DS-300136 DS-300147
Heritage style 19,5 cm (7,75”) 89 cm (35”) 21,5 cm (8,5”) 38 cm (15”) - - DS-300145 HANDLEBARS,
25,4 MM (1”) CLASSIC BENDS, BLACK CONTROLS &
Original Ape Hanger 32 cm (12,5”) 88 cm (34,5”) 21,5 cm (8,5”) 25,5 cm (10”) - 0601-0699 0601-0700 MIRRORS
Mini Ape Hanger 25,5 cm (10”) 87 cm (34,25”) 20,5 cm (8”) 25,5 cm (10”) - - 0601-0704

CABLES
DS-300126
DS-300155 DS-300220
BRAKES

DS-300205 DS-300150 OIL TANKS,
FILTERS &
GAS TANKS

DASHES
& GAUGES
0601-0708
0601-0706 0601-0711
CHASSIS,
SUSPENSION,
FENDERS
STYLE RISE WIDTH CENTER WIDTH PULLBACK UNKNURLED NO DIMPLES KNURLED DIMPLED KNURLED DRILLED & WHEELS
25,4 MM (1”) DRAG BARS, CHROME
Broomstick 66 cm (26”) - 66 cm (26”) - - - DS-300155 -
Broomstick 73,7 cm (29”) - 73,5 cm (29”) - - - DS-300121 DS-300220 FLOORBOARDS
Narrow center 18° - 70 cm (27,5”) 19 cm (7,5”) 10 cm (4”) DS-300199 DS-300200 DS-300219 & PEGS
Wide center 18° - 85 cm (33,5”) 24 cm (9,5”) 11,5 cm (4,5”) DS-300126 DS-300115 DS-300209
Wide center 25° - 82 cm (32,25”) 24 cm (9,5”) 16,5 cm (6,5”) DS-300116 DS-300111 DS-300218
27° Drag Bars - 58,5 cm (23”) 21,5 cm (8,5”) 11,5 cm (4,5”) DS-300205 - -
35° Drag Bars - 72,5 cm (28,5”) 19 cm (7,5”) 25,5 cm (10”) DS-300149 DS-300150 DS-300152 HARDWARE
25,4 MM (1”) DRAG BARS, BLACK
Broomstick 66 cm (26”) - 66 cm (26”) - - - 0601-0705 -
Broomstick 73,7 cm (29”) - 73,5 cm (29”) - - - 0601-0706 -
Narrow center 18° - 70 cm (27,5”) 19 cm (7,5”) 10 cm (4”) - 0601-0707 0601-0708
Wide center 18° - 85 cm (33,5”) 24 cm (9,5”) 11,5 cm (4,5”) - 0601-0709 0601-0710
Wide center 25° - 82 cm (32,25”) 24 cm (9,5”) 16,5 cm (6,5”) - 0601-0711 0601-0712 GENERAL

25,4 MM (1”) HANDLEBARS continued on next page
