25,4 MM (1”) VINTAGE AND VINTAGE SHORT STACK HANDLEBARS FENDERS
& WHEELS
•Available with chrome or black powder‑coat
•Chrome and black powder‑coated bars are knurled, slotted and drilled for internal wiring
•Standard bars have 89 mm (3 /2”) on‑center knurling; Springer bars have 12 cm (4 /4”) on‑center knurling FLOORBOARDS
3
1
•Feature chrome billet end caps & PEGS
•Made in the U.S.A.
PART # DESCRIPTION WIDTH RISE CENTER WIDTH PULLBACK
VINTAGE
0601‑0714 Chrome 76 cm (30”) 30,5 cm (12”) 16,5 cm (6,5”) 10 cm (4”) HARDWARE
0601‑0715 Chrome for Springer front ends 76 cm (30”) 30,5 cm (12”) 16,5 cm (6,5”) 10 cm (4”)
0601‑0716 Black powder‑coat 76 cm (30”) 30,5 cm (12”) 16,5 cm (6,5”) 10 cm (4”)
0601‑0717 Black powder‑coat for Springer front ends 76 cm (30”) 30,5 cm (12”) 16,5 cm (6,5”) 10 cm (4”)
VINTAGE SHORT STACK
0601‑0686 Chrome 76 cm (30”) 19 cm (7,5”) 16,5 cm (6,5”) 95 mm (3,75”)
0601‑0687 Chrome for Springer front ends 76 cm (30”) 19 cm (7,5”) 16,5 cm (6,5”) 95 mm (3,75”) GENERAL
0601‑0688 Black powder‑coat 76 cm (30”) 19 cm (7,5”) 16,5 cm (6,5”) 95 mm (3,75”)
0601‑0689 Black powder‑coat for Springer front ends 76 cm (30”) 19 cm (7,5”) 16,5 cm (6,5”) 95 mm (3,75”)
