25,4 MM (1”) 0601-2083
OLD SCHOOL HANDLEBARS
•Made with high-strength 25,4 mm (1”)
GASKETS diameter steel tubing
& SEALS •TIG welded for strength and appearance
•Drilled for internal wiring See chart for details
•Made in the U.S.A.
CHROME PART # BLACK PART # DESCRIPTION END RISE WIDTH CENTER WIDTH PULLBACK
ELECTRICAL 0601‑2052 0601‑2053 15 cm (6”) Narrow Z 15 cm (6”) 61 cm (24”) 15 cm (6”) 76 mm (3”)
& LIGHTING 0601‑2054 0601‑2055 20,5 cm (8”) Narrow Z 20,5 cm (8”) 61 cm (24”) 15 cm (6”) 76 mm (3”)
0601‑2056 0601‑2057 25,5 cm (10”) Narrow Z 25,5 cm (10”) 61 cm (24”) 15 cm (6”) 76 mm (3”)
0601‑2058 0601‑2059 30,5 cm (12”) Narrow Z 30,5 cm (12”) 61 cm (24”) 15 cm (6”) 76 mm (3”)
HANDLEBARS, 0601‑2289 0601‑2290 25,5 cm (10”) Web Z 25,5 cm (10”) 61 cm (24”) 15 cm (6”) 76 mm (3”)
CONTROLS & 0601‑2291 0601‑2292 30,5 cm (12”) Web Z 30,5 cm (12”) 61 cm (24”) 15 cm (6”) 76 mm (3”)
MIRRORS 0601‑2060 0601‑2061 20,5 cm (8”) Bourbon Ape Hanger 20,5 cm (8”) 71 cm (28”) 15 cm (6”) 76 mm (3”)
0601‑2062 0601‑2063 25,5 cm (10”) Bourbon Ape Hanger 25,5 cm (10”) 71 cm (28”) 15 cm (6”) 76 mm (3”)
0601‑2064 0601‑2065 30,5 cm (12”) Bourbon Ape Hanger 30,5 cm (12”) 71 cm (28”) 15 cm (6”) 76 mm (3”)
‑ 0601‑2067 1 20,5 cm (8”) EZ Rider T-Bars 20,5 cm (8”) 61 cm (24”) 89 mm (3,5”) -
CABLES 0601‑2068 1 0601‑2069 1 25,5 cm (10”) EZ Rider T-Bars 25,5 cm (10”) 61 cm (24”) 89 mm (3,5”) -
0601‑2076 1 0601‑2077 1 25,5 cm (10”) Reverse T-Bars 25,5 cm (10”) 66 cm (26”) 89 mm (3,5”) 76 mm (3”)
0601‑2078 ‑ 15 cm (6”) Window 15 cm (6”) 66 cm (26”) 15 cm (6”) 76 mm (3”)
‑ 0601‑2083 25,5 cm (10”) Window 25,5 cm (10”) 66 cm (26”) 15 cm (6”) 76 mm (3”)
1 TÜV approved.
BRAKES
25,4 MM (1”)
OIL TANKS, JACKRABBIT HANDLEBARS
FILTERS & •Straight wrist angles and a skinny stance give 0601-2008
GAS TANKS this bar cool 70’s style
•Machine formed for precision old-school looks 0601-2009
with modern accuracy
•25,4 mm (1”) integral risers to hug the triple trees
DASHES (89 mm on-center (3 /2”))
1
& GAUGES •Not dimpled or drilled
•Made in the U.S.A.
CHASSIS, CHROME PART # BLACK PART # END RISE WIDTH CENTER WIDTH PULLBACK
SUSPENSION, 0601‑2008 0601‑2009 25,5 cm (10”) 73,5 cm (29”) - 10 cm (4”)
FENDERS
& WHEELS
32 MM (1 /4”)
1
OLD SCHOOL HANDLEBARS
FLOORBOARDS 1 0601-2298
& PEGS •Made with high-strength 32 mm (1 /4”)
diameter steel tubing 0601-2311
•TIG welded for strength; welds polished
for seamless appearance
•Drilled for internal wiring
HARDWARE •Laser-cut web design adds style and strength
•Made in the U.S.A.
CHROME PART # BLACK PART # DESCRIPTION END RISE WIDTH CENTER WIDTH PULLBACK
‑ 0601‑2296 15 cm (6”) Narrow Z 15 cm (6”) 210 cm (4”) 15 cm (6”) 76 mm (3”)
‑ 0601‑2298 20,5 cm (8”) Narrow Z 20,5 cm (8”) 210 cm (4”) 15 cm (6”) 76 mm (3”)
GENERAL 0601‑2299 0601‑2300 25,5 cm (10”) Narrow Z 25,5 cm (10”) 210 cm (4”) 15 cm (6”) 76 mm (3”)
‑ 0601‑2302 30,5 cm (12”) Narrow Z 30,5 cm (12”) 210 cm (4”) 15 cm (6”) 76 mm (3”)
0601‑2311 ‑ 30,5 cm (12”) Web Z 30,5 cm (12”) 210 cm (4”) 15 cm (6”) 76 mm (3”)
