IRONHEAD XL

SEATS & 25,4 MM (1”) HANDLEBARS (CONT)
SISSY BARS

DS‑300227
EXHAUST
DS‑300133
CARBURETORS
& AIR FILTERS

ENGINE DS‑300130

TRANSMISSION
& DRIVELINE

GASKETS DS‑300122
& SEALS
DS‑300129
ELECTRICAL
& LIGHTING

DS‑300132
HANDLEBARS,
CONTROLS &
MIRRORS
DS‑300324

CABLES

DS‑300327
BRAKES

OIL TANKS, DS‑300202
FILTERS &
GAS TANKS

DASHES
& GAUGES DS‑300120

CHASSIS,
SUSPENSION,
FENDERS DS‑300173
& WHEELS

FLOORBOARDS
& PEGS STYLE RISE WIDTH CENTER WIDTH PULLBACK UNKNURLED NO DIMPLES KNURLED DIMPLED KNURLED DRILLED
25,4 MM (1”) CUSTOM BENDS, CHROME
883 type 89 mm (3,5”) 75 cm (29,5”) 11,5 cm (4,5”) 18 cm (7”) - DS-300135 DS-300227
Bad Boy 89 mm (3,5”) 82 cm (32,25”) 18 cm (7”) 18 cm (7”) - DS-300133 DS-300229
Flat Track 13,5 cm (5,25”) 87 cm (34,25”) 18 cm (7”) 21,5 cm (8,5”) - DS-300130 -
HARDWARE
13,5 cm (5,25”) 80 cm (31,5”) 11 cm (4,25”) 21 cm (8,25”) - DS-300122 -
Swept Back 11 cm (4,25”) 79 cm (31”) 18 cm (7”) 28 cm (11”) - DS-300129 -
11 cm (4,25”) 71 cm (28”) 12 cm (4,75”) 28 cm (11”) - DS-300132 -
Wide Clubman bar 64 mm (2,5”) 80 cm (31,5”) 21,5 cm (8,5”) 19 cm (7,5”) DS-300324 - -
Narrow Clubman bar 64 mm (2,5”) 73 cm (28,75”) 14,5 cm (5,75”) 18 cm (7”) DS-300327 - -
GENERAL Low Cafe 64 mm (2,5”) 83 cm (32,5”) 12 cm (4,75”) 12,5 cm (5”) DS-300202 - -
Beach/ Knucklehead 89 mm (3,5”) 91 cm (35,75”) 21,5 cm (8,5”) 27,5 cm (10,75”) - DS-300120 -
Super Glide type 20,5 cm (8”) 81 cm (32”) 19 cm (7,5”) 32 cm (12,5”) - DS-300173 -

664 ALL PART NUMBERS IN BLUE ARE NEW
