CUSTOM BENDS (CONT)
PART # BLACK PART # DESCRIPTION END RISE WIDTH CENTER WIDTH PULLBACK
0601‑0836 ‑ Sweeper bars (dimpled) 27,5 cm (10,90”) 80 cm (31,57”) 21,5 cm (8,50”) 19 cm (7,54”)
0601‑0837 ‑ Sweeper bars (dimpled) 27,5 cm (10,83”) 87 cm (34,07”) 30,5 cm (12”) 20 cm (7,84”) CABLES
0601‑0823 ‑ Buckhorn bars (dimpled) 16 cm (6,28”) 70,5 cm (27,84”) 20 cm (7,95”) 23,5 cm (9,27”)
0601‑0825 ‑ Fatboy‑style bars (undimpled/ undrilled) 11 cm (4,27”) 83 cm (32,57”) 30,5 cm (12,09”) 23 cm (9,01”)
0601‑0842 0601‑1693 Low‑rise drag bars (dimpled) 69 mm (2,70”) 67 cm (26,30”) 16 cm (6,31”) 13,5 cm (5,32”)
0601‑0827 ‑ Tall Heritage style bars (dimpled) 33 cm (13,13”) 81 cm (32,01”) 21,5 cm (8,52”) 13,5 cm (5,34”)
‑ 0601‑1692 XLS‑style bars, black (dimpled) 12 cm (4,64”) 69 cm (27,14”) 12 cm (4,71”) 12 cm (4,85”) BRAKES

OEM REPLACEMENT BENDS
CHROME PART # DESCRIPTION END RISE WIDTH CENTER WIDTH PULLBACK
0601‑0815 For 83‑85 XLS; repl. OEM #56082‑83 12 cm (4,64”) 69 cm (27,14”) 12 cm (4,71”) 12 cm (4,85”) OIL TANKS,
FILTERS &
GAS TANKS

DASHES
& GAUGES

CHASSIS,
SUSPENSION,
FENDERS
& WHEELS
0601‑1977

FLOORBOARDS
& PEGS

25,4 MM (1”) NARROW APE HANGERS
•Now available in 30,5 cm or 40,5 cm (12” or 16”) tall versions HARDWARE
•Dimpled and diamond‑knurled for OEM risers on 89 mm (3 /2”) centers 0601‑1976
1
•Drilled for internal wiring
•Available in duplex nickel chrome plated or gloss black paint
•Made in the U.S.A.
CHROME PART # BLACK PART # DESCRIPTION END RISE WIDTH CENTER WIDTH PULLBACK GENERAL
0601‑1977 ‑ 30,5 cm (12”) 25,5 cm (10,00”) 77 cm (30,50”) 12,5 cm (5”) 17,5 cm (6,91”)
0601‑1975 0601‑1976 40,5 cm (16”) 34,5 cm (13,65”) 81 cm (32,00”) 12,5 cm (5”) 17 cm (6,79”)

ALL PART NUMBERS IN BLUE ARE NEW 661
