IRONHEAD XL

25,4 MM (1”) HANDLEBARS (CONT) SEATS &
SISSY BARS

0601-2173
EXHAUST

CARBURETORS
& AIR FILTERS

ENGINE
0601-2193

TRANSMISSION
& DRIVELINE

0601-2167
GASKETS
& SEALS

0601-3182 ELECTRICAL
& LIGHTING

HANDLEBARS,
CONTROLS &
0601-2163 MIRRORS

0601-2160 CABLES
0601-2176

0601-2200 BRAKES

0601-2185 OIL TANKS,
FILTERS &
GAS TANKS

DASHES
& GAUGES

CHASSIS,
SUSPENSION,
CHROME PART # BLACK PART # DESCRIPTION END RISE WIDTH CENTER WIDTH PULLBACK FENDERS
0601-2174 0601-2173 Window, dimpled 17 cm (6,75”) 68,5 cm (27”) 12,5 cm (5”) 38 mm (1,5”) & WHEELS
0601-2192 0601-2191 Breezer 89 mm (3,5”) 68,5 cm (27”) 12 cm (4,75”) 14 cm (5,5”)
0601-2194 0601-2193 Breezer, dimpled 89 mm (3,5”) 68,5 cm (27”) 12 cm (4,75”) 14 cm (5,5”)
0601-2168 0601-2167 Chumps 13,5 cm (5,25”) 77 cm (30,5”) 12 cm (4,75”) 16,5 cm (6,5”) FLOORBOARDS
0601-2170 0601-2169 Chumps, dimpled 13,5 cm (5,25”) 77 cm (30,5”) 12 cm (4,75”) 16,5 cm (6,5”) & PEGS
0601-3182 0601-3181 Flyers 16,5 cm (6,5”) 81 cm (32”) 19 cm (7,5”) 16,5 cm (6,5”)
0601-3184 0601-3183 Flyers, dimpled 16,5 cm (6,5”) 81 cm (32”) 19 cm (7,5”) 16,5 cm (6,5”)
0601-2164 0601-2163 Apes 24 cm (9,5”) 81 cm (32”) 12 cm (4,75”) 16,5 cm (6,5”)
0601-2166 0601-2165 Apes, dimpled 24 cm (9,5”) 81 cm (32”) 12 cm (4,75”) 16,5 cm (6,5”) HARDWARE
0601-2160 0601-2159 Frisco 18 cm (7”) 72,5 cm (28,5”) 14 cm (5,5”) 19 mm (0,75”)
0601-2162 0601-2161 Frisco, dimpled 18 cm (7”) 72,5 cm (28,5”) 14 cm (5,5”) 19 mm (0,75”)
0601-2176 0601-2175 Low Drag 95 mm (3,75”) 70 cm (27,5”) 64 mm (2,5”) 76 mm (3”)
0601-2178 0601-2177 Low Drag, dimpled 95 mm (3,75”) 70 cm (27,5”) 64 mm (2,5”) 76 mm (3”)
0601-2200 0601-2199 H-Bar 20,5 cm (8”) 56 cm (22”) 64 mm (2,5”) 70 mm (2,75”)
0601-2202 0601-2201 H-Bar, dimpled 20,5 cm (8”) 56 cm (22”) 64 mm (2,5”) 70 mm (2,75”) GENERAL
0601-2184 0601-2183 High Drag 18 cm (7”) 66 cm (26”) 64 mm (2,5”) 76 mm (3”)
0601-2186 0601-2185 High Drag, dimpled 18 cm (7”) 66 cm (26”) 64 mm (2,5”) 76 mm (3”)

657
ALL PART NUMBERS IN BLUE ARE NEW
