IRONHEAD XL

25,4 MM (1”) HANDLEBARS (CONT)
SEATS &
See chart SISSY BARS
for details

EXHAUST
0601‑0571

CARBURETORS
& AIR FILTERS

0601‑0572
ENGINE

0601‑0573
TRANSMISSION
& DRIVELINE

GASKETS
0601‑0574 & SEALS

ELECTRICAL
0601‑0575
& LIGHTING
0601‑1024
HANDLEBARS,
CONTROLS &
MIRRORS
DS‑300400
CABLES

0601‑1227
BRAKES

OIL TANKS,
FILTERS &
0601‑2654 GAS TANKS

DASHES
& GAUGES
0601‑0743
CHASSIS,
SUSPENSION,
FENDERS
& WHEELS
CHROME PART # BLACK PART # DESCRIPTION END RISE WIDTH CENTER WIDTH PULLBACK
0601‑0571 ‑ Dragster X‑wide ‑ 79 cm (31”) 26,5 cm (10,5”) 16 cm (6,25”)
0601‑0572 ‑ Buckhorn medium 23 cm (9”) 86 cm (34”) 22 cm (8,75”) 25,5 cm (10,125”) FLOORBOARDS
0601‑0573 ‑ Buckhorn low 17 cm (6,75”) 79 cm (31,25”) 22 cm (8,675”) 23 cm (9”) & PEGS
0601‑0574 ‑ Buckhorn high 33 cm (13”) 84 cm (33”) 22 cm (8,75”) 34,5 cm (13,5”)
0601‑0575 ‑ Flat track 11,5 cm (4,5”) 77 cm (30,5”) 19 cm (7,5”) 28,5 cm (11,25”)
0601‑0576 0601‑1024 Superbar 89 mm (3,5”) 76 cm (30”) 14,5 cm (5,75”) 14,5 cm (5,75”)
0601‑0577 0601‑1227 Beach bar 11,5 cm (4,5”) 91 cm (36”) 19,5 cm (7,75”) 36 cm (14,25”) HARDWARE
DS‑300400 0601‑2652 3 15 cm (6”) T‑Bar 10 cm (4”) 79 cm (31”) 21,5 cm (8,5”) 26,5 cm (10,5”)
DS‑300403 2 0601‑2655 3 15 cm (6”) T‑Bar 10 cm (4”) 79 cm (31”) 21,5 cm (8,5”) 26,5 cm (10,5”)
DS‑300401 0601‑2653 3 20,5 cm (8”) T‑Bar 12,5 cm (5,0”) 79 cm (31”) 21,5 cm (8,5”) 29 cm (11,5”)
DS‑300404 2 0601‑2656 3 20,5 cm (8”) T‑Bar 12,5 cm (5,0”) 79 cm (31”) 21,5 cm (8,5”) 29 cm (11,5”)
DS‑300402 0601‑2654 3 25,5 cm (10”) T‑Bar 15 cm (6,0”) 79 cm (31”) 21,5 cm (8,5”) 32 cm (12,5”)
DS‑300405 2 0601‑2657 3 25,5 cm (10”) T‑Bar 15 cm (6,0”) 79 cm (31”) 21,5 cm (8,5”) 32 cm (12,5”) GENERAL
0601‑0743 ‑ Stick style ‑ 76 cm (30”) ‑ ‑
2 Dimpled and drilled for internal wiring. 3 Not TÜV approved.
