COMPACT CHAIN BREAKER CHAIN RIVETING TOOL
•For 420 to 530 chain •Versatile enough to be used on
•Will push link pin completely through P502 cam chains or drive chains
link/ side plate •Will break chains from
TIRES & •Handle folds away for easy storage #35 to #530
TUBES •Replaceable pin is heat-treated for strength •For chain #520 and up, it is
and wear resistance recommended to grind the
•Will not work on EK 530 MVO/ MVX rivet head P558
•Max pin extension to drive out chain links is P501 •Includes three pin sizes to fit
18 mm; the maximum pin extension required most chains
to drive out the chain link is determined by measuring your chain’s (2 mm, 3 mm, 4 mm)
width from outside face plate to outside face plate •Investment-cast, hardened
•Made in the U.S.A. body and redesigned body bolt
PART # DESCRIPTION PART # DESCRIPTION •Recommended for light to medium-duty use
P501 Chain breaker P502 Repl. pin •For riveting hollow nose master links
•Riveting tool includes press plates PART #P567
PART # DESCRIPTION PART # DESCRIPTION
P566 P558 Chain riveting tool P561 4 mm tip
P559 2 mm tip P562 Wedge tip
P560 3 mm tip P567 Repl. press plates

P567
CHEMICALS, CHAIN PRESS TOOL
HARDWARE •Installs press-fit side plates on rivet-type MP08-135
& TOOLS connecting links
•For use on #520 and #530 chain, including
O-ring types
•Complete chain press tool includes press pads
•Does not rivet chain 3806-0011
•PART #3806-0011 (sold separately) converts chain press tool to a chain
breaker and riveting tool JUMBO CHAIN TOOL
•Made in the U.S.A. •Designed to break roller chain
PART # DESCRIPTION up to #630 – fits all standard and
P566 Chain press tool O-ring chain sizes #520 to #630
P567 Press pads only •Designed to rivet chain up to #530 (not #630) 3806-0010
3806‑0011 Breaking and riveting conversion kit •Masterlink side plate press kit included to press on
side plates on chains up to #530 (not #630)
•Screws and attachments are heat treated for strength and durability
•The extractor pin is precisely guided by a removable guide, ensuring
long pin life
•May be bolted to a work bench, supported in a vise or held by handle
LICENSE •When bolted to a solid surface, air or electric wrenches may be used
to break chain
PLATE •Recommended for heavy-duty use
FRAMES
•Replacement pin is made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION
MP08‑135 Jumbo chain tool 3806‑0010 Repl. pin
T6 CHAIN TOOL
•For breaking 520 to
530 chain
•For pressing on and off 520 and some 525 master link side plates
•For clip-type master links with press-fit side plates
•Lightweight, 6 oz. net wt. including press plates and handle (8 oz. net
wt. with pouch)
•Will push link pin completely through link/ side plate
•Handle detaches for easy storage; to reduce the weight even more
an MP Tool (PART #MP08-0161), 8 mm combination wrench or 8 mm
socket with extension can be used as the handle CHAIN BREAKER,
•Custom pouch holds tool securely and includes pocket for extra PRESS AND
chain/ master links and a large accessory pocket
•Body forged from high-strength 4130 chromoly RIVETING TOOL
•Body bolt and extractor bolt manufactured from billet high-strength •Complete chain tool for most 520, 525 and 530 standard
WINDSHIELDS 7075 T-6 aluminum and O-ring chains
•Replaceable pin is heat-treated for strength and wear resistance •Break, press, and rivet your chain with one compact tool
•Press plates manufactured from light weight 6061 T-6 aluminum •Will rivet hollow-nose master links (will not rivet solid soft-nose pins)
•This tool does not rivet chains or master links •Will push pin completely through link/ side plate
•Perfect for any tool pack •Hardened body, riveting tip and breaker pin for strength
5
•Handle accommodates the use of Motion Pro’s /16” bits; this feature and durability
eliminates the need for a separate /16” bit driver to carry around on •Removable handle for compact storage
5
those long rides •Perfect for your tool pack if you have a chain with a rivet master link
PART # DESCRIPTION PART # DESCRIPTION
3806‑0009 T6 chain tool 3806‑0014 Chain breaker, press and riveting tool
