GENERAL

STEERING STEM
BEARING TOOL
•Removes and installs tapered roller
bearing at base of steering stem
TIRES & •Durable black oxide finish with laser engraved logo
TUBES •Compact design to fit within steering stops on lower triple clamp
•Removal process requires cutting outer sheet metal cage from tapered roller bearing unit
•Bearing driver adapter installs new bearing without damage to bearing or steering stem PART # DESCRIPTION
•Fits most Harley‑Davidson motorcycles with tapered roller bearing 3805‑0118 Steering stem bearing tool for H‑D

STEERING STEM NECK
BEARING TOOL BEARING TOOL
•Removes and installs •Slips under the tapered roller
tapered roller bearing bearing on the lower triple tree to allow safe and
at base of steering stem easy removal
•Includes 26 mm, 28 mm, 30‑31 mm and 35‑36 mm •Used with any standard “T” puller and two pieces
5
race protectors for installing bearing race of /16”‑18 threaded rod
•Compact design to fit within steering stops on lower triple clamp •Made in the U.S.A.
•Blue anodized bearing protectors made from 6061 billet aluminum PART # DESCRIPTION
and laser etched for easy identification DS‑196015 Neck bearing tool
•Removal process requires cutting outer sheet metal cage from
bearing assembly
•Protects steering stem during bearing removal and installation process NECK BEARING ADJUSTER TOOL
•Fits most motorcycles with tapered roller bearing at base
CHEMICALS, of steering stem •Tapered end allows easy access to the neck
HARDWARE PART # DESCRIPTION bearing adjusting star on H‑D front ends
& TOOLS •18 /2” long
1
3805‑0115 Steering stem bearing tool
PART # DESCRIPTION
3850‑0165 Neck bearing adjuster tool

STEERING HEAD
BEARING RACE INSTALLER
•Use to install races and cups straight and
true in the steering head
•Made in the U.S.A.
PART # DESCRIPTION SWINGARM
DS‑198625 For 36‑84 Big Twin w/ stock or custom frames
BUSHING TOOL
•Allows installation of delicate,
silicone cleveblock bushings in
swingarm without damage
CLEVEBLOCK •Tool presses on outer sleeve
of bushing
LICENSE SPREADING TOOL •Can be used with or without
PLATE •Tool spreads the swingarm cleveblocks, a press
FRAMES allowing for the installation of the swingarm
•Comes with instructions PART # DESCRIPTION
•Made in the U.S.A. DS‑196067 For 84‑01 FLT, FLHT, 84‑99 FXR and all aftermarket FXR‑style frames
PART # DESCRIPTION
DS‑196066 For 80‑83 5‑speed rubber‑mount frames

WHEEL
WHEEL ALIGNMENT TOOL LUG WRENCH
•For rear wheel alignment •Reproduction of original factory wrench
•Fast, accurate and easy to use •Strong, handy tool to remove or replace brake
•Eliminates the need to use a tape measure drum wheel socket screws
•Proper wheel alignment extends chain/ sprocket and belt life •Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION
3811‑0015 For FX and XL 2401‑0528 For 36‑72 Big Twin

WINDSHIELDS
MASTER
LINK PLIERS
MASTER LINK PLIERS •Designed to install and remove
•Saves time installing and removing chains clip‑type master links
•The specially formed pliers pull the end link rollers close together, •One tip is shorter and notched to be placed on
allowing for a quick and simple master link installation or removal the pin; the other tip is longer to push the clip easily
PART # DESCRIPTION PART # DESCRIPTION
3801‑0257 Master link pliers MP08‑0230 Master link pliers

802 ALL PART NUMBERS IN BLUE ARE NEW
