COMPENSATING SHAFT SPROCKET NUT SOCKET
•Used to remove and install compensating nut
1
• /2” drive for easier installation than wrench
TIRES & •Made in the U.S.A.
TUBES PART # DESCRIPTION
DS‑196175 For 55‑70 Big Twin and XL

CLUTCH FOOT LEVER
CLUTCH LOCK PLATE BRACKET BUSHING
•Used to keep clutch shell from INSTALLATION TOOL
turning when engine sprocket nut •Simplifies the installation or
or clutch hub nut is being removed removal of bushings
•Made in the U.S.A. •Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION
DS‑199222 For all 41‑E84 Big Twin 2401‑0537 For 36‑78 Big Twin; repl. OEM #36857‑36

CHEMICALS,
HARDWARE
& TOOLS

TRANSMISSION BEARING CLUTCH SPRING COMPRESSOR
HOUSING REMOVER •Used to remove or install clutch components
AND INSTALLER •Made in the U.S.A.
•Use on all 80‑83 Big Twin to remove and PART # DESCRIPTION
install bearings on 5‑speeds and aftermarket DS‑196059 For 71‑E84 XL; repl. OEM #97178‑71
6‑speeds
•Can also be used to pull trapdoors on 80‑83 Shovelhead Big Twin
5‑speeds and aftermarket 6‑speeds
•Made in the U.S.A.
NOTE: Housing bearings must be replaced when pulling door.
LICENSE PART # DESCRIPTION
PLATE 3802‑0034 For 80‑83 Shovelhead 5‑speeds and aftermarket 6‑speeds MAIN DRIVE GEAR BEARING/
FRAMES SEAL INSTALLATION TOOL
•Use to install both bearings and seal with
use of a one‑ton press
•Holds bearings and seal square to its
bore, eliminating any marring
•Installs bearings and seal to
correct depth
•Made in the U.S.A.
4-SPEED MAINSHAFT PART # DESCRIPTION
For 80‑83 5‑speed Big Twin
DS‑196070
CLUTCH GEAR PULLER
•Removes starter clutch gear successfully,
without damage to the gear
•Made in the U.S.A.
PART # DESCRIPTION
DS‑198626 For 36‑84 Big Twin w/ kick‑start 4‑speed transmission

MAIN DRIVE
WINDSHIELDS
TRANSMISSION GEAR TOOL
ACCESS COVER •Used to install the
main drive gear and
PULLER TOOL install main bearing
•Use to remove transmission access covers, without removing
which are press‑fit on two dowel pins the transmission
•Made in the U.S.A. •Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION
DS‑196150 For 54‑85 XL DS‑196055 For 80‑83 Big Twin 5‑speed
