GENERAL

DS‑196154
BIG TWIN
TRANSMISSION
MAIN SEAL TOOL
•Use to install seals on
41‑79 Big Twin transmissions MAIN DRIVE GEAR TIRES &
TUBES
•Optional drivers used in SEAL INSTALLER
conjunction with main •Use to install main drive
shaft seal tool allow gear oil seal to the proper
installation of seals depth with transmission assembled
•Tool and drivers sold separately DS‑196288 •Includes protective sleeve for seal, which can be used to protect main
•Made in the U.S.A. drive gear inner bearings during installation
PART # DESCRIPTION •Made in the U.S.A.
DS‑196154 Main shaft seal tool for 41‑79 Big Twin PART # DESCRIPTION
DS‑196288 Optional seal driver for 82‑83 Big Twin 4‑speed DS‑198634 For all 80‑83 5‑speed Big Twin

DS‑196162

DS‑196163
SHIFT FORK GAUGE
•Used to set and align shift forks on 4‑speed Big Twin CHEMICALS,
•Made in the U.S.A. HARDWARE
STEERING HEAD PART # DESCRIPTION PART # DESCRIPTION & TOOLS
RACE PULLER DS‑196162 For 79‑84 Big Twin DS‑196163 For 39‑78 Big Twin
•Designed to quickly and precisely
remove outer bearing race from
the steering head without the use of a hammer
and punch
•Puller design ensures bearing is pulled perfectly
straight to eliminate possible damage to frame
•Works on all tapered bearing races with 47 mm to
52 mm O.D.
•Brass bearing washers for easy use and long life
•Hardened steel jaws engage securely on inner bearing lip SHIFTER SHAFT
PART # DESCRIPTION SLEEVE TOOL
3805‑0133 Steering head race puller •Use to install shifter shaft sleeve
•Can be used to remove, install replacement or upgrade shifter shaft
sleeve, assembly and drum
•Made in the U.S.A.
LICENSE
PART # DESCRIPTION
3802‑0008 For upgrades to latest shifter assembly PLATE
on 5‑speeds, 80‑83 FLT/ FLHT/ FXR FRAMES

5-SPEED TRANSMISSION MAIN DRIVE GEAR
SHAFT INSTALLER BEARING TOOL
•Installs transmission shaft without the use of a •Use to install the main
hydraulic or arbor press bearing (H‑D #8905) to the
•Made in the U.S.A. correct depth
•Made in the U.S.A.
PART # DESCRIPTION
DS‑197083 For 83 Big Twin PART # DESCRIPTION
DS‑196073 For 79‑84 4‑speed Big Twin

DS‑196005
STEERING HEAD
BEARING RACE
DRIVER STEERING HEAD
•Fits all tapered steering BEARING RACE TOOL WINDSHIELDS
bearings 41 mm to 56 mm •Removes and installs steering head bearing race on 49‑84
•Installs the tapered bearing Big Twin and 78‑85 Sportster frames (will also work on
race in the frame most aftermarket frames) DS‑196029
•Made of durable 6061‑T6 anodized aluminum •Must be used with tool driver spacer PART #DS‑196029
•Ergonomic aluminum anodized handle and handle/ driver PART #DS‑196042; sold separately
•Unique double‑sided drivers •Made in the U.S.A.
•Laser‑etched for easy identification PART # DESCRIPTION
PART # DESCRIPTION DS‑196005 Bearing race tool
3805‑0110 Steering head bearing race driver DS‑196029 Tool driver spacer
