GENERAL

CLUTCH
HUB PULLER
•Use to remove CLUTCH SPRING
clutch hubs COMPRESSION TOOL TIRES &
•Removes the hub •This tool makes it easy to remove TUBES
without removing the and re‑install retainer rings on
transmission end cover diaphragm clutches
on Big Twin models •Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION
DS‑196061 For 41‑84 Big Twin and 71‑E84 XL DS‑199221 For L84‑85 XL

CLUTCH HUB PULLER FOR
PRO CLUTCH AND
PRIMO DIAPHRAGM
SPRING CLUTCHES CLUTCH HUB REMOVING DRIVER
•Kit includes puller, center bolt and •Use to remove clutch hub from the
four nuts transmission mainshaft
•Makes pulling a Pro Clutch or Primo •Slight tap onto the transmission mainshaft to remove CHEMICALS,
diaphragm clutch easy clutch hub HARDWARE
•Made in the U.S.A. •Left‑hand thread & TOOLS
PART # DESCRIPTION PART # DESCRIPTION
DS‑196021 Clutch hub puller SS‑D For 36‑84 Big Twin

INNER PRIMARY
BEARING LICENSE
RACE TOOL PLATE
•Used to remove and install FRAMES
UNIVERSAL the inner primary bearing race
CLUTCH •Works on left‑ and right‑side drive 5‑ or 6‑speed transmissions
HUB PULLER •Made in the U.S.A.
•Can be used on 3‑, 5‑ or 10‑finger clutch hubs PART # DESCRIPTION
For L84 Big Twin primaries
3802‑0002
and 45” clutch hubs
•Will also work on Big Twin motor sprocket,
alternator cover and early XL clutches as well as many
other applications
•Made in the U.S.A.
PART # DESCRIPTION
DS196286 Clutch hub puller

WINDSHIELDS
TRANSMISSION SCORPION CLUTCH LOCK PLATES
•Specifically designed to be used to lock outer clutch
DOOR PULLER basket to inner hub for removal and installation
•Removes transmission •Made in the U.S.A.
door with gears and shaft attached PART # DESCRIPTION
•Puller will not damage door bearings 3803‑0011 Scorpion clutch lock plate set (set of 4)
•Made in the U.S.A. 3803‑0010 For 84‑85 XL
PART # DESCRIPTION 3803‑0009 For 71‑83 XL
DS‑198630 For 80‑83 Big Twin 5‑speeds 3803‑0008 For 36‑E84 Big Twin

ALL PART NUMBERS IN BLUE ARE NEW 799
