m-RELAY
•Small, compact relay EXHAUST
•Designed to control almost any kind of device including high‑beam light, driving light, horn,
ignition, etc.
•Moves high loads and currents directly to the switched devices
•Enhances the electrical reliability of your bike CARBURETORS
•Reduces voltage drops in power supply & AIR FILTERS
•Load and current at the handlebar switch gear and ignition lock is reduced to a minimum
allowing small diameter wiring at the switch gear for easier wiring
•CNC‑machined and black anodized
•Molded internally, waterproof and vibration resistant
•Two red cables allow the connection of devices for 12V power supply and up to 20A load current ENGINE
•Two black cables allow the connection of the switch gear
•Not intended as a control unit
for push buttons PART # DESCRIPTION
•Easy‑to‑install 2020‑0462 m‑Relay TRANSMISSION

& DRIVELINE

GASKETS
& SEALS
m-FLASH DIGITAL FLASHER 2020‑0463
•Replaces all conventional flasher relays; only uses two cables
•Perfect for custom bikes and modifications with limited space ELECTRICAL
•Route through the handlebar, frame tubing or in the cable harness & LIGHTING
•Constant and correct flashing rate; suitable for almost all LED blinkers and all micro‑blinkers 2020‑0464
•Works with four signal lights or two handlebar end blinkers and has an immediate,
lossless flasher response
•Features an automatic overload protection; doesn’t generate heat during operation HANDLEBARS,
•Takes 5V to 18V to operate; suitable for 6V flashers CONTROLS &
•Water and short circuit proof MIRRORS
•Does not require load resistors or similar accessories
•PART #2020‑0463 is suitable for all LED blinkers, micro blinkers, halogen blinkers
and bulb blinkers from 1W‑100W
•m‑Wave PART #2020‑0464 is the first flasher relay to allow a smooth fade in/ fade CABLES
out with your flash lights
PART # DESCRIPTION PART # DESCRIPTION
2020‑0463 m‑Flash digital relay 2020‑0464 m‑Wave digital relay

BRAKES

OIL TANKS,
FILTERS &
GAS TANKS
3
14,5 CM (5 /4”) QUARTZ LIGHT
•12V quartz halogen light manufactured by SMALL GLOBE BULBS DS‑282012‑PK 2060‑0026 DASHES
Candlepower comes complete with H4 P43T •12V; approximately 26,2 mm L x 18,3 mm diameter (1,03” L x 0,720”) & GAUGES
60/ 55W bulbs; replacement bulbs PART # DESCRIPTION
also available DS‑282012‑PK Clear, dual‑filament (10‑pk.)
•Twice the illumination of standard sealed beams 2060‑0202 Clear, 8/ 23W, double‑filament (pr.) CHASSIS,
3
•Available in 14,5 cm (5 /4”) size with special locating tab for H‑D DS‑282013 Clear 21/5W, dual‑filament (10‑pk.) SUSPENSION,
headlight housings 2060‑0026 Amber 23/8W, dual‑filament (pr.) FENDERS
PART # DESCRIPTION DS‑282080 Amber 21/ 6cp, dual‑filament (10‑pk.) & WHEELS
DS‑280009 12V, 60/ 55W 2060‑0332 Red 21/ 6cp, dual‑filament (10 pk.)

FLOORBOARDS
& PEGS

HARDWARE
INDICATOR LIGHT BULBS
•12V, #73 style LARGE GLOBE BULB
•Approximately 19 mm L x 5,1 mm diameter (0,750” L x 0,200”) •12V (1157/ BAY15D style); 25,4 mm (1”) diameter globe
•Sold to dealers in packs of 10 •Sold to dealer in 10‑pk. GENERAL
PART # DESCRIPTION PART # DESCRIPTION
DS‑282096PK Clear 1,4W, single‑filament 2060‑0181 Red 32/3 cp, dual‑filament
