DRAG/V-TWIN TOOLS

DS‑196277 DS‑196094
STREET
TIRES
PISTON PIN BUSHING TOOL
FOR 36‑99 BIG TWIN, 57‑16 XL
AND BUELL (EXCEPT 1125R) DRAG/
•Use to remove and install wrist pin bushings without removing rods V-TWIN TIRES
from crankcase
DESCRIPTION PART #
Piston pin bushing tool DS‑196159

SCOOTER
TIRES
ROD ALIGNMENT TOOLS
ROD LAPPING SET •Use to check rod straightness without removing
the rods from the cases
FOR ALL BIG TWIN AND XL •Alignment tool is 4,5” long OFFROAD
MODELS (EXCEPT TWIN CAM) •Available in Twin Cam and Evolution applications TIRES
DESCRIPTION PART #
•Arbor assembly includes 1,5” and For Twin Cam, 0,927” wrist pin DS‑196277
1,625” laps
•For use on all Big Twins that have For Evolution, 0,791” wrist pin DS‑196094 ATV/UTV

replaceable races, including
aftermarket engines TIRES &
DESCRIPTION PART # WHEELS
Rod lapping set DS‑196164

TUBES &
5 /16” STUD INSTALLATION TOOL ACCESSORIES
•Designed to set Twin Cam and Evolution exhaust studs, Shovelhead rocker
box studs, 4-speed transmission end studs, Bendix & Keihin carb flange
EVOLUTION CYLINDER studs and most other /16” studs
5
STUD ASSEMBLY TOOL PART # DESCRIPTION SHOP EQUIPMENT
•Assembly tool features a captive hardened ball bearing DS‑196039 5 /16” stud installation tool & STANDS
dimensionally set 1” from top of tool
•Made of high tensile steel
•Works on all Evolution Big Twin and XL models GENERAL,
DESCRIPTION PART # METRIC SERVICE/
Stud assembly tool 3801‑0045 MAINTENANCE

TOOLS
CYLINDER SLEEVE
HOLD‑DOWNS
•Specialty nuts are used to hold down cylinder sleeves DRAG/
during service V-TWIN TOOLS
•Allow motor to be turned over with heads off
3
EXHAUST STUD •Nuts fit /8”-16 UNC thread
•Feature /4” hexagon with a small cylinder protruding down to catch the
3
DRILL PLATE cylinder stud
FOR 84‑17 BIG TWIN •Case-hardened and zinc-plated CHEMICALS &
LUBRICANTS
•Sold in packs of four
(EXCEPT M‑EIGHT), 86‑17 XL AND PART # DESCRIPTION
94‑09 BUELL (EXCEPT 1125R) 3801‑0199 For Evolution Big Twin, Sportster and Twin Cam w/ 3 /8” stud
•Designed to drill broken exhaust studs
•Can be used with most motors still in the frame CLEANERS,
1
•Includes drill bushing and /4” drill bit POLISHES &
DESCRIPTION PART # PAINTS
Exhaust stud drill plate DS‑197032

TRANSPORT
& TRAILER
EXHAUST GASKET SEAL
INSTALLER TOOL EXHAUST RING MERCHANDISING
FOR 84‑13 BIG TWIN AND XL RETAINER TOOL
•Installs fragile exhaust seal with ease and will •Quickly and easily installs the exhaust pipe
position seal evenly to exhaust port of head retaining ring on almost all H-D exhaust systems
•Can be used with exhaust flange nuts or JIMS •Install the H-D No. 65325-83A ring in seconds, without scratching the
handle PART #DS-196042; sold separately exhaust pipe or twisting the ring INDEX
DESCRIPTION PART # DESCRIPTION PART#
Exhaust gasket seal installer tool 3850‑0121 Exhaust ring retainer tool 3850‑0227

451
All part numbers in BOLD MAGENTA are new this year.
