DRAG/V-TWIN TOOLS

                             VALVE GUIDE REMOVER/ INSTALLER
                 •Use for removing and installing valve guides                                                            STREET
                 •Adapters are supported by a stand that makes it easy to press valve guides in and out                   TIRES
                 •A special guide alignment shaft holds the right angle for best possible guide installation
                 •Save time and money on seat grinding by installing the guides in line with the valve seats  3801-0170
                 •Kit includes base assembly, six adapters, three assembly pilots, three inserts and instructions  DS-196310
                 •Adapters for working on 7 mm valve guides available separately
                 DESCRIPTION                                 PART #  DESCRIPTION                                  PART #  DRAG/
                 For 48-04 Big Twin, 57-03 XL and some S.E. CVO Twin Cam models  DS-196310  Adapter for 7 mm valve guide insert  3801-0171  V-TWIN TIRES
                 Adapter for 7 mm valve guide assembly pilot  3801-0170

                    VALVE GUIDE REMOVAL/                                                       3801-0134
                    INSTALLATION TOOLS FOR                                                                                SCOOTER
                    SHOULDERLESS GUIDES                                   3801-0136  3801-0137                            TIRES
                 •Available from JIMS to allow the proper          DS-196077
                 removal or installation of shoulderless valve guides as well as valve seals    DS-196074
                 DESCRIPTION                                                                                      PART #
                 .560” dia. sleeve for correctly installing all Evolution and 99-04 Twin Cam valve guides, use w/ PART #DS-196074; repl. OEM #34731-84  DS-196077  OFFROAD
                 Sleeve for correctly installing all 05-17 Twin Cam, 04-17 XL, 04-09 Buell (except 1125CR) 7 mm valve guides; use w/ PART #DS-196074  3801-0136  TIRES
                 Sleeve for correctly installing all Evolution valve guide seals, use w/ PART #DS-196074; repl. OEM #34643-84  DS-196078
                 Sleeve for correctly installing all 110” valve guide seals using H-D seal No. 18046-98; use w/ PART #DS-196074  3801-0137
                 Remover for 05-17 Twin Cam 7 mm valve guides, 04-17 XL, 04-09 Buell (except 1125R)               3801-0134
                 Driver/  handle for removing all Evolution and 99-04 Twin Cam guides; should also be used w/ tools listed above  DS-196074  ATV/UTV

                                                                                                                          TIRES &
                                                                                                                          WHEELS

                                                            3801-0286
                                                                                                                          TUBES &
                                                                               7 MM VALVE GUIDE REAMER                    ACCESSORIES
                                                                      FOR 05-17 TWIN CAM (EXCEPT SE MODELS), 04-17 XL
                                                                     •Quality pilot lead-in reamer is made of high-speed steel
                                                                     •For 7 mm valve guides H-D No. 16461-02 that are used in conjunction with   SHOP EQUIPMENT
                    VALVE GUIDE SEAL INSTALLATION TOOLS               the latest conical (Beehive) valve springs          & STANDS
                 •Manufactured from high-strength 6061 T-6 aluminum for increased   •Will also work on equivalent aftermarket 7 mm valve guides
                 durability when compared to plastic installers      DESCRIPTION                                  PART #
                 •Precision fitment onto the seal OD to help the builder center the seal over   7 mm valve guide reamer  3801-0180
                 the valve guide so that a few light strikes from a hammer will set the seal                              GENERAL,
                 •Radiused top striking surface reduces the likelihood of a burr forming                                  METRIC SERVICE/
                 from deformation                                                                                         MAINTENANCE
                 •Available in a kit of four tools or separately
                 •Kit PART #3801-0286 includes installation tools for 99-04 Twin Cam, 84-99                               TOOLS
                 Evolution Big Twin, 86-03 Evolution XL, 66-84 Shovelhead, 48-65 Panhead
                 and 57-E83 Ironhead XL
                 •Single installation tools fit models listed in chart                                                    DRAG/
                 PART #        DESCRIPTION                                                                                V-TWIN TOOLS
                 COMPLETE INSTALLATION KIT
                 3801-0286     Installation kit
                 REPLACEMENT INSTALLATION TOOLS                               SHOULDERED VALVE
                 3801-0287     For 99-04 Twin Cam, 84-99 Evolution Big Twin, 86-03 Evolution XL
                 3801-0288     For L79-84 80” Shovelhead                       GUIDE DRIVER SET                           CHEMICALS &
                 3801-0290     For 48-65 Panhead, 66-E79 74” Shovelhead  •Three-piece set ( /8”,  /32”,  /16”) used to remove or install   LUBRICANTS
                                                                                    11
                                                                                 3
                                                                                        5
                 3801-0289     For 57-E83 Sportster                   valve guides

                                                                     DESCRIPTION                                  PART #
                                                                     Valve guide driver set                       DS-199100
                                                                                                                          CLEANERS,
                                                                                                                          POLISHES &
                                                                                                                          PAINTS
                                                                           3801-0241
                                                                                                                          TRANSPORT
                   3801-0230  3801-0231  3801-0232  3801-0233  3801-0234                                                  & TRAILER
                               VALVE GUIDE SEALS                        VALVE GUIDE REAMERS FOR MANGANESE
                 •Seals sold each, in 25-packs and 100-packs                      BRONZE VALVE GUIDES
                 •Stem diameter  /16”; guide OD 0,420”               •Can be used in an electric or battery-powered hand drill  MERCHANDISING
                            5
                 PART #                                     DESCRIPTION  •All cutting diameters are +/- 0,0002” and include a 1,000” long pilot
                 SEAL DRIVER (EA.)                                   •Sold each
                 3801-0230                                  Black    PART #      DESCRIPTION   CUTTING LENGTH  OVERALL LENGTH
                 3801-0231                                  Red      3801-0244   0,3100” reamer  2,626”       7,125”
                 SLEEVES CAPSULE FOR VALVE STEM (PR.)                3801-0241   0,3110” reamer  2,626”       7,125”
                 3801-0232                                  5 /16” green  3801-0242  0,3770” reamer  2,626”   7,125”      INDEX
                 3801-0233                                  11 /32” yellow  3801-0243  0,3780” reamer  2,626”  7,125”
                 3801-0234                                  3 /8” red  3801-0253  7 mm reamer  2,626”         7,125”
