CAMSHAFT REMOVAL/
INSTALLATION TOOL
•For 99-06 Twin Cam (except 06 Dyna) for removing/
SCOOTER installing cams and bearings; for 00-06 FXST/FL and
L00-05 FXD to remove and install cams only
TIRES •Used to remove and install camshafts and bearings
•Provides precision alignment of camshafts in the support plate
DESCRIPTION PART #
Camshaft removal/ installation tool DS‑196199
OFFROAD
TIRES 3801‑0068

ATV/UTV CAM BEARING INSTALLER
TIRES & CAM BEARING PULLER AND REMOVER TOOL
WHEELS •Removes the cam ball bearings from the camshafts •Made from hardened steel
after they are removed from the support plate •Includes removal shaft with installer and hold-down bolts
•For 99-06 Twin Cam (except 06 Dyna) for removal of •Update kit includes removal shafts required for use on models listed
bearings; for L00-06 FXST/FL and L00-05 FXD for removal PART # DESCRIPTION
TUBES & of front cam bearing DS‑198809 For 99-06 Twin Cam; repl. OEM #42325
ACCESSORIES •Removes bearing straight without binding or slipping 3801‑0068 Update kit for 06 Dyna and all 07-17 Twin Cam models
DESCRIPTION PART #
Cam bearing puller DS‑196193

SHOP EQUIPMENT
& STANDS

CAM COVER PULLER
GENERAL, 3801‑0061
METRIC SERVICE/ •Designed to remove the cam cover
MAINTENANCE PART # DESCRIPTION
TOOLS DS‑196170 For 70-99 74” and 80” Big Twins, and 70-03 XL models

DRAG/
V-TWIN TOOLS
CAM COVER
HOLDING TOOL INNER CAM BEARING REMOVAL TOOL
CHEMICALS & FOR 70‑99 BIG TWIN, •Used to remove inner cam bearing without damaging the crankcase
LUBRICANTS EXCEPT TWIN CAM •Tool is also designed to keep rollers from falling into the crankcase
•Clamps in vice •Comes with instructions
•Holds cam cover flat and helps DESCRIPTION PART #
prevent damage/ scratches when For 00-06 Twin Cam motors (except 06 FXD) DS‑196198
CLEANERS, removing and installing bushings For 06 Dyna models and all 07-17 Twin Cam models 3801‑0061
POLISHES & DESCRIPTION PART # For 58-99 Big Twin, except Twin Cam DS‑196156
PAINTS Cam cover holding tool DS‑196144 For 57-90 XL DS‑197056

TRANSPORT REAMER TOOL
& TRAILER FOR CAM
PLATE RELIEF
VALVE BORE
•Use this reamer to perform CAM ASSEMBLY TOOL
MERCHANDISING a ‘valve job’ on the pressure FOR 06 DYNA MODELS AND
relief valve seat of any Twin Cam engine cam plate
•Can be used on OEM or aftermarket cam plates ALL 07‑17 TWIN CAM MODELS
•To use, lightly machine the cam plate relief valve seat and re-seat the •Holds both cams in an upright position while
plunger valve lowering cam support plate over both guides and cam journal guides
®
•Best used in conjunction with Feuling pressure testing tool •Made from a non-marring material that will not damage any of the
INDEX PART #3801-0071 cams’ surfaces
PART # DESCRIPTION DESCRIPTION PART #
3801‑0252 For 99-17 Twin Cam models Cam assembly tool 3801‑0066
