IRONHEAD XL

1710‑0284 SEATS &
SISSY BARS

EXHAUST

STAINLESS STEEL 11 /2” FRONT BRAKE ROTORS CARBURETORS
1
•Polished, stainless steel front brake rotors include adapter & AIR FILTERS
•Sold each
•Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION
FOR 84-85 XL FOR 84-85 XL (CONT) ENGINE
1710-0283 Left 1710-0284 Right

TRANSMISSION
& DRIVELINE

GASKETS
2-PISTON FRONT & SEALS
BRAKE CALIPERS
•Billet aluminum with a smooth or classic “fin”
design in a choice of three finishes: clear ELECTRICAL
anodized, chrome or black contrast
•Select styles now available in a chrome finish & LIGHTING
5
•All single‑disc applications require a /8” bore
master cylinder
•Brake pads included HANDLEBARS,
•Made in the U.S.A. CONTROLS &
NOTE: Not recommended for use with MIRRORS
imported stainless steel rotors. 1701‑0225 1701‑0226
NOTE: When installing new calipers, always
check spoke-to-caliper clearance.
CABLES
PART # DESCRIPTION PART # DESCRIPTION
FOR 74-77 XL (SINGLE DISC) (“B” CALIPER) FOR 74-77 XL (SINGLE DISC) (“B” CALIPER) (CONT)
1701-0223 Classic anodized 1701-0226 Smooth black
1701-0224 Classic black 1701-0227 Smooth chrome
1701-0225 Classic chrome BRAKES

2-PISTON CUSTOM REAR CALIPERS OIL TANKS,
•Billet aluminum with classic “fin” or smooth designs FILTERS &
•Choice of three finishes: clear anodized, chrome or black contrast GAS TANKS
•Raw metal on black contrast calipers is anodized for a long‑lasting high‑quality finish
•Hanger brackets and brake pads included
•Made in the U.S.A. DASHES
NOTE: The OLD-STYLE Wagner and Kelsey-Hayes (die-cast aluminum OEM) on rear & GAUGES
3
applications have a /4” bore master cylinder and WILL NOT WORK CORRECTLY.
NOTE: Not recommended for use with imported stainless steel rotors. 1701‑0258 1701‑0261
5
NOTE: Requires use of /8” bore master cylinder. CHASSIS,
SUSPENSION,
PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION FENDERS
FOR 82-85 XL (“B” CALIPER) FOR 79-81 XL (“B” CALIPER) FOR 79-81 XL (“B” CALIPER) (CONT)
1701-0265 Classic chrome 1701-0258 Classic clear anodized 1701-0262 Smooth chrome & WHEELS
1701-0266 Smooth black 1701-0259 Classic black contrast
1701-0267 Smooth chrome 1701-0261 Smooth black FLOORBOARDS

& PEGS
1720‑0075 1702‑0058
1702‑0061
HARDWARE
1720‑0076 1702‑0059
GMA REPLACEMENT CALIPER COMPONENTS
PART # DESCRIPTION PART # DESCRIPTION
1720-0075 Repl. brake pads for “A” calipers (set of 2) 1702-0059 Caliper pistons for front or rear “B” calipers (2‑pk.) GENERAL
1720-0076 Repl. brake pads for “B” calipers (set of 2) 1702-0061 Complete caliper O‑ring/ seal kit for “A” or “B” calipers
1702-0058 Caliper pistons for front or rear “A” calipers (2‑pk.)

ALL PART NUMBERS IN BLUE ARE NEW 691
