IRONHEAD XL

SEATS &
SISSY BARS

EXHAUST

CARBURETORS
& AIR FILTERS

ENGINE
STERLING CHROMITE II BRAIDED
THROTTLE AND IDLE CABLES
®
TRANSMISSION •Sterling Chromite II uses patented technology to look like chrome
& DRIVELINE •Braid color and weave matches on all Magnum control cables and brake lines
•Coated with a non-yellowing crystal clear outer jacket for exceptional
protection against scuffing paint or chrome
•All fittings are polished and chrome plated
GASKETS •Meet or exceed all OEM specifications for fitment, construction
& SEALS •All cables are made with anti-friction inner liners, nylon adjuster inserts, and
are factory lubricated for smooth consistent long-lasting operation
•Made in the U.S.A.
NOTE: Length given is length of outer housing only, excluding elbows.
ELECTRICAL
& LIGHTING STOCK LENGTH THROTTLE IDLE CABLES
FITS MODEL THROTTLE PART # OEM # HOUSING LENGTH TRAVEL IDLE PART # OEM # HOUSING LENGTH TRAVEL ELBOW
FOR 74‑85 XL MODELS
1
1
81-85 XLH DS‑3301 56324-81C 82,5 cm (32 /2”) 95 mm (3 /4”) DS‑3401 56323-81C 82,5 cm (32 /2”) 102 mm (4”) 45°
3
HANDLEBARS, 74-80 XLH DS‑3303 56313-76 84 cm (33”) 102 mm (4”) ‑ - - - 90°
CONTROLS & 81-82 XLS DS‑3301 56324-81C 82,5 cm (32 1 /2”) 95 mm (3 /4”) DS‑3401 56323-81C 82,5 cm (32 /2”) 102 mm (4”) 45°
3
1
MIRRORS 79-80 XLS DS‑3303 56313-76 84 cm (33”) 102 mm (4”) ‑ - - - 90°
74-80 XLCH DS‑3303 56313-76 84 cm (33”) 102 mm (4”) ‑ - - - 90°

CABLES
BRAKES Sterling Chromite II

OIL TANKS, STERLING CHROMITE II BRAIDED
FILTERS & HIGH EFFICIENCY CLUTCH CABLES
®
GAS TANKS •Sterling Chromite II uses patented technology to look like chrome
•Braid color and weave matches on all Magnum cables and brake lines
•Low effort, high efficiency cable design meets or exceeds all OEM
DASHES specifications for fitment, construction, and endurance requirements
& GAUGES •All cables are covered with a non-yellowing crystal clear outer jacket for
exceptional protection against scuffing paint or chrome
•All fittings are polished and chrome plated
CHASSIS, •Attractive chrome plated adjuster with integrated water-resistant seals does
SUSPENSION, not require a boot
FENDERS •Rubber seal in transmission fitting eliminates fluid leaks
& WHEELS •All cables are made with anti-friction inner liners, nylon adjuster inserts, and
are factory lubricated for smooth and consistent long-lasting operation
•Made in the U.S.A.
FLOORBOARDS NOTE: Check torque spec on transmission fitting when installing.
& PEGS HOW TO MEASURE CLUTCH CABLES
NOTE: Cables are measured with the adjuster completely collapsed.
STANDARD LENGTH HIGH EFFICIENCY CLUTCH CABLES
FITS MODEL PART # HOUSING LENGTH ADJUSTER LOCATION FROM TRANS TRAVEL OEM #
HARDWARE
FOR 71‑85 XL MODELS
1
11
71-85 XLH 0652‑1027 119,5 cm (47 /16”) Bottom 170 mm (6 /16”) 38619-84
81-85 XLS 0652‑1027 119,5 cm (47 1 /16”) Bottom 170 mm (6 /16”) 38619-84
11
71-79 XLCH 0652‑1027 119,5 cm (47 1 /16”) Bottom 170 mm (6 /16”) 38619-84
11
ALTERNATIVE LENGTH HIGH EFFICIENCY CLUTCH CABLES FOR CUSTOM HEIGHT/ WIDTH HANDLEBARS
GENERAL FOR 71‑85 XL MODELS
11
0652‑1027 119,5 cm (47 /16”) - 170 mm (6 /16”) -
1
11
0652‑1026 135 cm (53 1 /16”) - 170 mm (6 /16”) -

686 ALL PART NUMBERS IN BLUE ARE NEW
