IRONHEAD XL

CLASSIC CALIPER KITS
SEATS & •The number one name in custom
SISSY BARS brake calipers
•Precision‑machined from billet aluminum
•Calipers are four‑piston, dual‑action design
for positive stopping power
•Pads included See chart
EXHAUST •Made in the U.S.A. for details 1701‑0482
NOTE: For replacement brake pads refer to the brake pad pages later in this section. DS‑325100
FRONT
CARBURETORS PART # DESCRIPTION PART # DESCRIPTION
& AIR FILTERS FOR 84‑85 XL W/ CAST WHEELS AND 11,5” ROTORS (125 X 4R CALIPER) FOR 84‑85 XL W/ STOCK OR CUSTOM WIRE SPOKE WHEEL AND
DS‑325100 Single disc, chrome 11,5” ROTORS (125 X 4SL CALIPER)
DS‑325051 Single disc, polished DS‑325103 Single disc, chrome
DS‑325101 Dual disc, chrome DS‑325055 Single disc, polished
DS‑325053 Dual, disc, polished DS‑325104 Dual disc, chrome
ENGINE
REAR
PART # DESCRIPTION PART # DESCRIPTION
FOR 84‑85 XL W/ 11,5” ROTORS (125 X 4RSPH CALIPER) FOR 84‑85 XL W/ 11,5” ROTORS (125 X 4RSPH CALIPER) (CONT)
DS‑325077 Chrome 1701‑0482 Contrast Cut
TRANSMISSION DS‑325108 Polished
& DRIVELINE
REPLACEMENT COMPONENTS
PART # DESCRIPTION PART # DESCRIPTION
1701‑0123 1 Polished 4‑piston caliper (125 x 4S ) DS‑325082 Brake pad pin (2‑piston calipers)
GASKETS 1701‑0122 1 Chrome 4‑piston caliper (125 x 4S) DS‑325083 Caliper mount shim kit ( 3 /8”)
& SEALS 1701‑0104 1 Polished 4‑piston caliper (125 x 4R) DS‑325084 Caliper mount shim kit ( 5 /16”)
1701‑0103 1 Chrome 4‑piston caliper (125 x 4R) DS‑325085 Brake pad clevis pin (sold each; 2 required) (4‑piston calipers)
DS‑325078 Caliper rebuild kit (4‑piston calipers) DS‑325086 Anti‑rattle spring (sold each; 2 required) (2‑piston calipers)
DS‑325081 Cotter pin (front calipers) 1 TUV approved.
ELECTRICAL
& LIGHTING

HANDLEBARS, VINTAGE REAR
CONTROLS & CALIPERS AND BRACKETS
MIRRORS •Braking power comes from Performance 1701‑0534 1701‑0535 1701‑0536
Machine’s proven 4‑piston internals, with styling cues taken from the Dual Action Cast caliper
•CNC‑machined fins give the caliper its vintage style while keeping the caliper cool and providing optimal 1701‑0509
braking power with no flex
CABLES •The precision‑machined Performance Machine logo around the accent bolt and centrally located banjo are
the finishing touches to a true classic
•Available in chrome, Black Ops™, Machine Ops™ and black finishes
•Black Ops is a gloss black finish on top of a contrasting textured black finish for outstanding toughness and design
•Machine Ops is a fusion of textured natural aluminum and detailed machining that exposes the aluminum alloy’s true
BRAKES
beauty, then the freshly machined parts get a slick clear anodized finish to protect the surface while keeping its raw
aesthetic protected
•Calipers and brackets sold separately 1701‑0533
OIL TANKS, •Made in the U.S.A. 1701‑0532
FILTERS & PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION
GAS TANKS REAR CALIPERS (125 X 4R) REAR CALIPERS (125 X 4R) (CONT) REAR CALIPERS (125 X 4R) (CONT)
1701‑0534 Chrome 1701‑0535 Black Ops 1701‑0536 Machine Ops

PART # DESCRIPTION PART # DESCRIPTION
3
3
DASHES REAR BRACKETS FOR RIGID/ CUSTOM FRAMES W/ 10” ROTOR, /4” AXLE REAR BRACKETS FOR RIGID/ CUSTOM FRAMES W/ 11,5 “ ROTOR, /4” AXLE
& GAUGES 1701‑0509 Black 1701‑0530 Black
1701‑0510 Chrome 1701‑0531 Chrome
1701‑0511 Machine Ops 1701‑0532 Machine Ops
CHASSIS, 1701‑0533 Chrome anchor rod 1701‑0533 Chrome anchor rod
SUSPENSION,
FENDERS
& WHEELS
FLOORBOARDS
& PEGS
FRONT CHROME
BRAKE FRONT FRONT
CALIPER KITS DUAL-DISC CHROME
HARDWARE •OEM‑style caliper in chrome finish CALIPER SET BRAKE
•Complete with all necessary mounting •Comes complete with brake pads CALIPER
hardware and brake pads •Calipers work with stock fork legs •Direct bolt‑on 4‑piston design for left side
NOTE: Check caliper-to-wheel clearance on •Accepts OEM mounting hardware and •Includes brake pads and bleeder screws
custom wheels. bushings (not included) •Uses 00‑07 Big Twin‑style replacement pads
GENERAL PART # DESCRIPTION PART # DESCRIPTION •Sold each
DS‑325385 For all 84‑85 XL single‑disc models (ea.) DS‑325317 For 78‑83 XL w/ dual‑disc front ends PART # DESCRIPTION
DS‑325383 For all 84‑85 XL dual‑disc models (pr.) (pr.); repl. OEM #s 44025‑79, 44026‑79 7805‑3045 For 84‑85 XL
