BRAKES BLACK VINYL THROTTLE AND IDLE CABLES
•Cables feature polished-chrome fittings, black vinyl outer casings, tempered-steel inner conduit and an inner nylon liner for smooth operation
and long life
OIL TANKS, •Available in undersize/ standard/ oversize lengths for most single and dual cable applications
FILTERS & NOTE: Throttle cables for 74-E76 models do not come with the 90° adjuster elbows. These cables fit into OEM throttle adjuster. If you do not
GAS TANKS have the stock adjuster, order the L76-E81 cable.
NOTE: Length given is the length of the outer housing only, excluding the elbow.
NOTE: Cables will also fit late style Mikuni carbs.
DASHES FITS MODEL THROTTLE PART # LENGTH ELBOW TRAVEL OEM # IDLE PART # LENGTH ELBOW TRAVEL OEM #
& GAUGES STOCK LENGTH VINYL THROTTLE AND IDLE CABLES
FOR 74-85 XL MODELS
3
1
81-85 XLH 0650-0344 82,5 cm (32 /2”) 45° 95 mm (3 /4”) 56324-81C 0651-0155 82,5 cm (32 /2”) 45° 102 mm (4”) 56323-81C
1
CHASSIS, 74-80 XLH 0650-0346 84 cm (33”) 90° 102 mm (4”) 56313-76 - - - - -
3
SUSPENSION, 81-82 XLS 0650-0344 82,5 cm (32 1 /2”) 45° 95 mm (3 /4”) 56324-81C 0651-0155 82,5 cm (32 /2”) 45° 102 mm (4”) 56323-81C
1
FENDERS 79-80 XLS 0650-0346 84 cm (33”) 90° 102 mm (4”) 56313-76 - - - - -
& WHEELS 74-79 XLCH 0650-0346 84 cm (33”) 90° 102 mm (4”) 56313-76 - - - - -
ALTERNATIVE LENGTH VINYL THROTTLE AND IDLE CABLES FOR CUSTOM HEIGHT/ WIDTH HANDLEBARS
FOR 81-85 XL MODELS
FLOORBOARDS 0650-1082 61 cm (24”) 90° 95 mm (3 /4”) - 0651-0643 61 cm (24”) 45° 102 mm (4”) -
3
& PEGS 0650-1084 76 cm (30”) 90° 95 mm (3 3 /4”) - 0651-0645 76 cm (30”) 45° 102 mm (4”) -
0650-1086 91,5 cm (36”) 90° 95 mm (3 3 /4”) - 0651-0647 91,5 cm (36”) 45° 102 mm (4”) -
3
1
0650-0404 100,5 cm (39 1 /2”) 90° 95 mm (3 /4”) - 0651-0235 100,5 cm (39 /2”) 90° 102 mm (4”) -
0650-0350 108 cm (42 1 /2”) 70° 95 mm (3 /4”) - 0651-0163 108 cm (42 /2”) 70° 102 mm (4”) -
1
3
0650-1088 112 cm (44”) 90° 95 mm (3 3 /4”) - 0651-0649 112 cm (44”) 45° 102 mm (4”) -
HARDWARE
0650-1090 122 cm (48”) 90° 95 mm (3 3 /4”) - 0651-0651 122 cm (48”) 45° 102 mm (4”) -
FOR 74-80 XL MODELS
0650-1092 61 cm (24”) 90° 102 mm (4”) - - - - - -
0650-1094 76 cm (30”) 90° 102 mm (4”) - - - - - -
0650-1096 91,5 cm (36”) 90° 102 mm (4”) - - - - - -
GENERAL 0650-0402 100,5 cm (39 1 /2”) 90° 102 mm (4”) - - - - - -
0650-1098 112 cm (44”) 90° 102 mm (4”) - - - - - -
0650-1100 122 cm (48”) 90° 102 mm (4”) - - - - - -

684 ALL PART NUMBERS IN BLUE ARE NEW
