Page 55 - Oldbook 2017

SHOVELHEAD

DOG DISH SEATS &
AIR CLEANER SISSY BARS
ASSEMBLY
3
•Features a hand-spun 5 /8” polished
aluminum cover with a high-quality
element for high flow as well as superior EXHAUST
protection from dust and dirt
•Includes a black powder-coated backing
plate and all necessary mounting hardware
•Made in the U.S.A. CARBURETORS
NOTE: Will require the separate purchase of a crankcase breather/ carb & AIR FILTERS
support bracket kit.
“TEARDROP” AIR CLEANER ASSEMBLY PART # DESCRIPTION
•Made from chrome-plated cast aluminum 1010‑1664 For S&S Super E carb
•Ribbed design; measures 8” x 4,5” x 2”
•Includes mini air filter and required hardware ENGINE
•Made in the U.S.A.
PART # DESCRIPTION
1010‑0710 For S&S Super E and G carbs
TRANSMISSION
1010-0192 & DRIVELINE
“BOB” RETRO-STYLE
AIR CLEANER
•Retro-style chrome-plated air
cleaner measures 5 /2” in diameter GASKETS
1
7” ROUND AIR CLEANER •Has a reuseable foam filter element & SEALS
•Chrome air cleaner fits Harley models •All necessary mounting hardware included
equipped with Bendix or Keihin •Replacement filter element available separately
butterfly carburetors NOTE: Requires appropriate carb support bracket.
•Air filter element included PART # DESCRIPTION ELECTRICAL
NOTE: Requires appropriate carb support bracket. 1010‑0192 For S&S E and G series carburetors & LIGHTING
PART # DESCRIPTION 1011‑0881 Repl. air filter element
DS‑288998 For Bendix and Keihin butterfly style carbs
HANDLEBARS,
CONTROLS &
DS-288999 MIRRORS

STAMPED STEEL CABLES
DRAGTRON™-STYLE AIR CLEANER BRACE
AIR CLEANER •Use with our Dragtron™ air cleaners to eliminate carb
vibration, which can lead to air leaks
•Stamped steel version of our popular •Includes hardware and template
die-cast Dragtron air cleaner •Must use either PART #DS-289104 block or OEM insulator
•Fits Bendix, Keihin and Tillotson carburetors •Chromed steel support braces fit models equipped with Bendix or BRAKES
NOTE: Requires appropriate carb support bracket. Keihin carbs
PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION
DS‑288999 Air cleaner DS‑289043 Repl. foam element DS‑289092 For 66-84 Shovelhead OIL TANKS,
FILTERS &
1014-0233 GAS TANKS

1014-0236
DASHES
& GAUGES
AIR CLEANER COVERS CHASSIS,
•Fit S&S, Super E or G carburetors SUSPENSION,
•Made from cast aluminum FENDERS
•Mount with stock hardware 1014-0231 & WHEELS
•Come in finned, fishscale or smooth pattern
•Available in a polished aluminum or black finish
PART # DESCRIPTION PART # DESCRIPTION FLOORBOARDS
POLISHED CHROME BLACK & PEGS
1014‑0231 Finned 1014‑0232 Finned
1014‑0233 Scales 1014‑0234 Scales
1014‑0235 Smooth 1014‑0236 Smooth

HARDWARE
SMOOTH STYLE CARBURETOR COVER
•Teardrop-style design
•Comes without element
•Available in chrome finish
•Made in the U.S.A. GENERAL
PART # DESCRIPTION
1015‑0099 For S&S carburetors on 66-84 Big Twin

ALL PART NUMBERS IN BLUE ARE NEW 53
