Page 54 - Oldbook 2017

SHOVELHEAD

SEATS &
SISSY BARS

EXHAUST
1014‑0120
1014‑0119
1014‑0116 1014‑0117
CARBURETORS
& AIR FILTERS
STEALTH AIR CLEANER COVERS
•Fit the S&S Stealth air cleaner kits 1014‑0177
•Bob and Muscle style air cleaner covers are
ENGINE machined from billet aluminum and fit over the end of the air
filter and leave the filter element exposed
•Air Stream‑style is die‑cast and features screened vents for
more air without sucking in rain/ road hazards
TRANSMISSION •Muscle‑style features muscle car‑style hood pins 1014‑0122
& DRIVELINE •Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION
1014‑0116 Air Stream, chrome 1014‑0120 Bobber dome, chrome 1014‑0123 Muscle, black wrinkle powder‑coat
1014‑0117 Air Stream, black wrinkle powder‑coat 1014‑0121 Bobber dome, black wrinkle 1014‑0177 Muscle, black wrinkle powder‑coat
GASKETS 1014‑0118 Bobber dish, chrome powder‑coat w/ logo
& SEALS 1014‑0119 Bobber dish, black wrinkle powder‑coat 1014‑0122 Muscle, chrome

1014‑0133
ELECTRICAL DS‑289130
& LIGHTING
AIR CLEANER AND COVERS
HANDLEBARS, •Original S&S chrome teardrop air cleaner assembly
CONTROLS & •Include an S&S cover, backing plate and high‑quality
MIRRORS filter element and hardware kit
•Increase horsepower with no other changes
•Made in the U.S.A.
CABLES NOTE: Covers may need to be notched when used with
custom or 5 US gal. or larger fuel tanks.
NOTE: Installation of an S&S air cleaner may require re-jetting. 1014‑0040
PART # DESCRIPTION PART # DESCRIPTION
AIR CLEANERS FOR S&S CARBURETORS REPLACEMENT PARTS (CONT)
BRAKES DS‑289130 For E & G series carbs 1014‑0133 Black wrinkle finish repl S&S air cleaner cover for E & G carbs
REPLACEMENT PARTS 1014‑0040 Chrome Slasher‑style air cover; repl. standard cover for all
DS289404 Repl. chrome S&S air cleaner cover for E & G carb E & G carb kits
DS289403 Repl. chrome S&S air cleaner cover for S&S CV and Super B carbs 1011‑1721 Repl. filter element for PART #DS‑289130
OIL TANKS,
FILTERS &
GAS TANKS 1010‑1313 1010‑0314
UNIVERSAL
DASHES STEALTH AIR
& GAUGES CLEANER KIT
•Stealth’s design incorporates
CHASSIS, a directional stinger that directs CUSTOM AIR
SUSPENSION, incoming airflow toward the CLEANER ASSEMBLIES
carburetor’s venturi
FENDERS •Increased performance •Increase horsepower with proper carburetor calibration
& WHEELS •Perfect addition to a performance •Mount directly to the carburetor
•Designed to fit most Shovelheads equipped with various carburetors
exhaust system •See CHEMICALS, HARDWARE & TOOLS section for cleaners
•Filter element can be cleaned
FLOORBOARDS and reused •Made in the U.S.A.
& PEGS •Kit includes backplate, air filter, all necessary mounting hardware and PART # DESCRIPTION
complete instructions AIR FILTER ASSEMBLIES
•Made in the U.S.A. 1010‑0314 For 76‑84 Shovelhead w/ Keihin butterfly carbs; 5” dia.
and polished outer cover (except all S&S E & G carbs)
NOTE: Cover not included, order one of the available covers 1011‑2663 For Bendix‑Tillotson carbs to 75
HARDWARE below separately. 1011‑1058 36‑38 mm Mikuni carbs; 5” dia. open round style
PART # DESCRIPTION 1011‑1059 36‑38 mm Mikuni carbs; 6” dia. chrome bonnet style
1010‑1313 Air cleaner kit for 66‑84 Big Twin w/ Super E or G carb RC‑0920 40‑45 mm Mikuni carbs; 5” dia. open round style
REPLACEMENT/ OPTIONAL COMPONENTS 1011‑1060 40‑45 mm Mikuni carbs; 6” dia. chrome bonnet style
1011‑3119 Pre‑filter, rainsock for standard air filter (PART #1010‑1313) REPLACEMENT FILTERS
GENERAL 1011‑3120 Pre‑filter, rainsock for +1” Stealth air filter (PART #1011‑2766) 1011‑2661 Repl. filter for 1011‑1059
1011‑2765 Repl. Stealth filter 1011‑2662 Repl. filter for 1011‑1060
1011‑2766 Opt. Stealth hi‑flo filter kit (1” taller) DS‑289057 Repl. filter for 1011‑2663

52 ALL PART NUMBERS IN BLUE ARE NEW
