SHOVELHEAD

SEATS &
SISSY BARS

SUPER STOCK GENERATOR ENGINE CASE
•Cast from A356 T‑6 heat‑treated aluminum alloy
EXHAUST
•Include crankcase bolts, washers and nuts, cylinder mounting
studs, timing hole plug, magnetic drain plug, assorted
breather and oil line fittings, top end oil screen spring and
plug, sprocket shaft Timken bearing assembly, oil seal,
®
CARBURETORS pinion shaft main bearing race, cam needle bearing assembly,
& AIR FILTERS oil pump shaft bushings and installation instructions 33‑4226
•Use Timken style sprocket shaft bearings and 1958 and later
pinion bearings (will not accept 1957 and earlier flywheels)
•Bearing races are all line honed and breather cavity is
precision machined to optimize breather timing for maximum
ENGINE
oil scavenging
7
1
•Machined for 3 /16” cylinders and tapped /4”‑20 for
gear covers, oil pump, tappet guides, timer
and timer advance
TRANSMISSION •66‑69 models use 66‑69 alloy inner primary 31‑0010
5
& DRIVELINE •Drilled for /16” generator mounting bolts
•Generator crankcase gear kit (includes
circuit breaker drive gear, idler gear, circuit
breaker gear and shims) and shafts must be
GASKETS purchased separately
& SEALS •Made in the U.S.A. 31‑2037 31‑2039
PART # DESCRIPTION PART # DESCRIPTION
31‑0010 66‑69 Generator engine cases 31‑2037 Circuit breaker drive gear shaft; repl. OEM #25856‑36
33‑4226 Generator crankcase gear kit 31‑2039 Idler gear shaft; repl. OEM #25791‑36
ELECTRICAL
& LIGHTING
HANDLEBARS,
CONTROLS &
MIRRORS SUPER STOCK™ ENGINE CASES DS‑194305
•Cast from A356 T‑6 heat‑treated aluminum alloy
1
5
•Cases are available for 3 /2” stock and 3 /8” big bore motors for any
CABLES stroke up to and including 5” and most stock length connecting rods
•Machined to accept an oil filter assembly that mounts on the front of
stock motor cases
•All races are line honed and breather cavity is precision machined to
optimize breather timing for maximum oil scavenging
BRAKES •Additional parts include crankcase bolts, washers and nuts, cylinder
mounting studs, timing hole plug, magnetic drain plug, assorted
breather and oil line fittings, oil screen, spring and plug, sprocket
®
shaft Timken bearing assembly and oil seal, pinion shaft main bearing
OIL TANKS, race, cam needle bearing assembly, oil pump drive shaft bushing and
FILTERS & installation instructions
GAS TANKS •Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION
FOR 70‑84 SHOVELHEAD FOR 70‑84 SHOVELHEAD (CONT)
5
DASHES DS‑194305 Standard bore DS‑194306 3 /8” bore
& GAUGES
CHASSIS,
SUSPENSION,
FENDERS
& WHEELS
ENGINE CASES
FLOORBOARDS •Feature 356 T‑6 permanent mold casings, standard American
& PEGS fasteners and gray cast‑iron inserts with /2” wall sections
1
•Manufactured to exact tolerances
•Timken bearings installed DS‑194315
•Pinion race‑installed and line‑lapped to standard size
HARDWARE •Cylinder studs installed
•O‑rings and gaskets are sold in a 10‑pack to dealers;
suggested retail is for paired gaskets and individual O‑rings
•Made in the U.S.A.
NOTE: Not for EFI applications.
GENERAL PART # DESCRIPTION PART # DESCRIPTION
FOR 70‑84 SHOVELHEAD FOR 70‑84 SHOVELHEAD (CONT)
DS‑194315 Standard bore cases 7806‑1558 Bottom plate O‑ring; 14‑hole (10‑pk.)

56 ALL PART NUMBERS IN BLUE ARE NEW
