GENERAL

PISTON
TIRES & PIN PULLER
TUBES •Removes pins from 12 mm‑25 mm
•Won’t damage piston or connecting rod
PART # DESCRIPTION
865 Piston pin puller

WRIST PIN BUSHING
REAMING TOOL PISTON PIN LOCK
•Used to ream wrist pin bushings to the RING TOOL
proper inner diameter •Used to install lock ring
•Can be used with rods in or out of the motor #22582‑52 in piston
•Lead‑in taper makes it easy to use •Made in the U.S.A.
•Made in the U.S.A. PART # DESCRIPTION
NOTE: Some wrist pin bushings will require a small amount of ball DS‑196166 For pre‑73 Big Twin and XL w/ 0,515” i.d. wrist pins
CHEMICALS, honing to give specified fit (see H-D manual for specifications).
HARDWARE
& TOOLS PART # DESCRIPTION
DS196501 For 73‑84 Shovelhead (0,7919”‑0,7923”)
DS196502 For 57‑85 XL (0,7913”‑0,7917”)

DELUXE
PISTON PIN
REMOVAL TOOL
•Interchangeable
piston adapters
•Made of durable
6061 aluminum
•Fits all piston pins
from /2” to 1”
1
•Works on both full skirt and
short skirt (slipper) pistons
•Non‑marring aluminum ROD HOLDER TOOL
pin adapters •Holds the rods in place when reaming or
•Durable blue anodized finish with laser‑engraved logo honing the wrist pin bushings
LICENSE •Patent pending •Made in the U.S.A.
PLATE
FRAMES PART # DESCRIPTION PART # DESCRIPTION
3801‑0147 Deluxe piston pin removal tool DS196276 For most V‑Twin applications

WRIST PIN REMOVER
•Used to remove the wrist pins on all PISTON PIN BUSHING TOOL
Harley‑Davidson motors •Use to remove and install wrist pin bushings
•Comes with instructions without removing rods from crankcase
•Made in the U.S.A. •Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION
DS‑196197 Wrist pin tool DS‑196159 For Big Twin and XL

WINDSHIELDS

CYLINDER TORQUE PLATES
•Torque plates must be used when boring or honing cylinders
•Simulate running stress conditions
•Come with instructions
•Made in the U.S.A.
PART # DESCRIPTION
DS‑196212 For 66‑84 Shovelhead cylinders (3,4375”‑4” bore w/ stock bolt pattern)

794 ALL PART NUMBERS IN BLUE ARE NEW
