TAPPET GUIDE PULLER TOOL TAPPET OIL SCREEN PLUG TOOL
•Used to remove press‑fit tappet •Used to remove the tappet oil screen plug
guides from crankcase •Removes oil screen without removing exhaust
•Made in the U.S.A. •Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION TIRES &
DS‑196155 For 57‑85 XL DS‑198638 For single cam Big Twin motors TUBES

TAPPET BLOCK
ALIGNMENT TOOL OIL PUMP SNAP RING INSTALLER
•Used to align oil hole from •Allows easy installation of outer snap ring on oil
crankcase to tappet block pump shaft without stretching the snap ring
•Sold each •Fits Big Twin oil pumps
•Made in the U.S.A. •Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION
DS‑197077 For L76‑84 Big Twin DS‑197058 Snap ring installer

TAPPET SCREEN
PLUG TOOL CHEMICALS,
•Compact design HARDWARE
•O‑ring on drive retains tool & TOOLS
7
in /16” wrench or socket OIL PUMP SEAL INSTALLER
• /16” drive allows more rotation •Easily installs oil pump seal below gear
7
without contacting motor surface for a no‑leak fit
•Flange design allows downward •For use on all Big Twin aluminum oil pumps
force to be applied to tool •Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION
3801‑0002 Tappet screen plug tool DS‑197059 Oil pump seal installer

CRANKCASE OIL
PASSAGE DRILLING JIG
•Used to install S&S oil pumps on early motor cases
•Jig is made from steel and heat‑treated for durability PART # DESCRIPTION
•Made in the U.S.A. DS‑197009 Oil pump jig
LICENSE
PLATE
FRAMES
53‑0027 1601‑2910

3801‑0073
MASTER FLYWHEEL BALANCING KIT WINDSHIELDS
•Kit includes a platform scale, two 500 g balance weights and a 1.000 g balance weight; one balance shaft, one balance shaft nut, one balance
stand and one rod support stand; taper adapters for 72‑84 Big Twin, a drive side shaft adapter for 77‑85 XL, and cam side shaft adapters for 58‑84
Big Twin; drive side shaft adapter for 55‑84 Big Twin, shaft adapter counterweight, drive side collar spacers and a 1.000 g bob weight assembly
•Works with OEM, S&S and any other flywheel that does not have pressed‑in crankpins
•Master flywheel balance kit also available without scale
•Includes a complete set of detailed instructions PART # DESCRIPTION
•Bob weight shim kit available separately 53‑0027 Master flywheel balance kit w/ scale
•For use with 37‑84 Big Twin and 57‑85 XL flywheels 1601‑2910 Master flywheel balance kit w/o scale
•Made in the U.S.A. 3801‑0073 Shim kit (includes two each 2,7 g; 5,4 g; 8,1 g; 10,8 g; 13,4 g and one each 50 g, 100 g)
