                     CAM COVER
                     HOLDING TOOL                                     INNER CAM BEARING
               TIRES &
                TUBES •Clamps in vice                                 INSTALLATION TOOL
                     •Holds cam cover flat and helps
                      prevent damage/ scratches when                  •Easily presses the inner cam
                                                                       bearing smoothly into the right
                      removing and installing bushings
                     •Made in the U.S.A.                               case with the cases assembled to
                                                                       the proper depth
                     PART #                              DESCRIPTION  •Made in the U.S.A.
                     DS‑196144                           For 70‑84 Big Twin
                                                                      PART #                               DESCRIPTION
                                                                      DS‑197047                            For 58‑84 Big Twin

                     INNER CAM                               DS‑196156
                     BEARING
                     REMOVAL
                     TOOL
                     •Used to remove inner cam bearing without damaging the crankcase
            CHEMICALS, •Tool is also designed to keep rollers from falling into the crankcase
             HARDWARE •Comes with instructions                        CAM BUSHING LINE REAMING TOOL
               & TOOLS  •Made in the U.S.A.                           •Finish size will be 0,0008”‑0,0015” over the cam journal
                     PART #                              DESCRIPTION  •Made in the U.S.A.
                     DS‑196156                           For 58‑84 Big Twin  PART #                        DESCRIPTION
                     DS‑197056                           For 57‑85 XL  DS‑196114                           For 70‑84 Big Twin

                                                                      CAM BEARING
                     INNER CAM BEARING                                AND BUSHING
                     GO AND NO-GO GAUGE                               ALIGNMENT
                     •The only accurate and easy way                  TOOL
                      to check the size of the inside                 •Use to check the
                      diameter of the inner                            alignment of cam
                      cam bearing                                      bearing to cam cover
                     •Use these gauges to check if                     bushing to within
                      your cam will be too loose or                    0,0003” of centerline
                      too tight                                       •Binding of tool
                     •Sold in a set of two                             indicates misalignment of cam cover and bushing
                     •Made in the U.S.A.                              •Made in the U.S.A.
               LICENSE  PART #                           DESCRIPTION  PART #                 DESCRIPTION
                PLATE  DS‑197010                         For 58‑84 Big Twin  DS196315        For 70‑84 Big Twin and aftermarket cases
               FRAMES

                                                    DS196313


                     DS‑196099
                                    DS‑196101




                        DS‑196100



            WINDSHIELDS CAM OR PINION BUSHING INSTALLER DRILL JIGS
                     •Use to install bushing and drill dowel pin hole to factory specification
                     •Use staking dowel pin PART #DS‑196313                            BIG TWIN CAM SEAL
                     •#31 jobber length HSS drill bit included with jigs               INSTALLER/ REMOVER
                     •Made in the U.S.A.                                               •Installs and removes cam seals without
                     PART #             DESCRIPTION                                    removing the cam cover
                     DS‑196099          For cam bushing OEM #25581‑70; 70‑84 Big Twin  •Use to remove cam cover from the case
                     DS‑196101          For cam bushing OEM #22586‑37; 37‑48 Big Twin sidevalve motors; 54‑85 XL  •Made in the U.S.A.
                     DS‑196100          For pinion bushing OEM #25582‑54/73; 54‑84 Big Twin  PART #        DESCRIPTION
                     DS196313           Staking dowel pins (10‑pk.)                    DS‑197036           For 70‑84 Big Twin
