GENERAL

GAUGE PINS
•Used to measure the outside diameter of cam drive gears DS199105
•Precision machined from a high-quality steel alloy
•Available in 0,105” or 0,108” dia.
•Sold in pairs
•Made in the U.S.A.
NOTE: There are two basic differences between 90-99 cam gear sizes and earlier years. The overall range of gear pin measurements (from the TIRES &
largest gears to the smallest) was reduced in 1990 from 0,006” to 0,003”. The large gears are the same size for both 84-89 and 90-99 (green TUBES
and black color codes). Gear size measurements (over pins) are listed in the 1990 H-D manual using 0,108” pins instead of 0,105” pins (as
for earlier years). For the same gear, measurement over 0,108” pins will be approximately 0,012” larger than for 0,105” pins. For 1992
engines, stock cam gears are interchangeable with earlier versions but gear outer diameters have been reduced by 0,025”.
PART # DESCRIPTION PART # DESCRIPTION
DS199105 0,105” gauge pins (pr.) DS‑199106 0,108” gauge pins (pr.)

INNER CAM BEARING
INSTALL TOOL DS-196044 DS-196043
•Use to install inner cam bearings
•Requires driver handle PART #DS-196042; sold separately
•Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION
DS‑196044 Cam bearing tool only for 58-84 Big Twin DS‑196043 Cam bearing tool only for 57-85 XL

CHEMICALS,
HARDWARE
& TOOLS
CAM AND PINION
GEAR GAUGE PINS
•Use to check pinion gear for pitch diameters
•A complete sizing chart is included with the
0,105” gauge pins
•Check service manual for sizing chart PINION BUSHING PULLER
•Sold in sets of two •Use to remove pinion bushing from cam
•Made in the U.S.A. cover in one easy operation
PART # DESCRIPTION •Use with cam cover holder PART #DS-196144
DS‑197011 0,105” for 54-84 Big Twin •Made in the U.S.A.
PART # DESCRIPTION
DS‑196157 For 54-84 Big Twin

LICENSE
PLATE
TOP DEAD FRAMES
PISTON PIN RETAINING RING CENTER TOOL
INSTALLER AND REMOVER •Tool makes it easy to find exact top
dead center of any engine
•Works on all pistons with retaining ring dimple •Invaluable when dialing in cams or performing any
•Insert claw in dimple and pull or push of a number of checks and modifications based on
•Made in the U.S.A. the position of the crankshaft
NOTE: Not recommended for use on forged pistons. •Available for engines with 14 mm spark plug holes
PART # DESCRIPTION PART # DESCRIPTION
DS‑198808 Retaining ring tool; repl. OEM #34623B 3801‑0024 14 mm

WINDSHIELDS

PISTON SUPPORT PLATE PISTON PIN
•Support plate gives a non-marring, flat KEEPER TOOL
surface to push piston bottoms against •Used to install piston pin
when installing rings or cylinders retaining rings
•Made in the U.S.A. •Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION
DS‑196407 Piston support plate DS‑199102 For 36-72 Big Twin
