All RK chains are prestressed and pre-stretched to ensure equal load distribution and minimal maintenance. They’re made of the highest-grade medium
WINCHES & carbon alloy steel available, with all components shot peened and heat treated.
MOUNTS
SPECIFICATIONS CHART
AUDIO & NOTE: Wear Life Index should be used as a comparison for probable wear life under identical circumstances. Think of it as a percent, with standard chains being 100.
VIDEO
SIZE AND TYPE WEAR LIFE INDEX AVERAGE TENSILE STRENGTH (LB) MAXIMUM ENGINE CC STREET/ DIRT
520 Std. 100 7200 250/NA
GENERAL 530 Std. 100 7200 400/NA
ACCESSORIES GB 420 MXZ 200 5000 150/ 100
GB 428 MXZ 200 5800 250/ 125
GB 520 MXZ4 300 9000 NA/ 500
RACKS & GB 520 MXU 600 9000 NA/ 500
ACCESSORIES 520 EXW, GB 520 EXW 1.000 8500 400/ 750

TRUNKS,
LUGGAGE &
STORAGE

BODY

ARMOR

HANDLEBARS
& CONTROLS

WHEEL
ACCESSORIES

BRAKES

BELTS, CHAINS
& SPROCKETS
RK CHAINS
DRIVETRAIN •RK chains are available cut-to-length and individually boxed with a clip-type connecting link
STANDARD (M) HEAVY DUTY (MXZ/4)
•Medium carbon alloy steel construction •Made for the serious motocross racer
SUSPENSION •Two-point pin riveting and solid rollers •Feature chromoly steel construction with seamless rollers and bushings,
•For motorcycles up to 500cc that did not come with an O-ring or heavy- and oversized alloy pins for added strength
duty chain as standard equipment •Ideal for professional level from 80cc to 500cc open class racing
•Chains include clip connecting link •Chains include clip connecting link
ENGINE SEALED UW‑RING (MXU) XW‑RING (EXW)
•The lightest sealed-ring MX chain on the market •High-speed, extreme heat performance chains that can handle large
FUEL/AIR •Designed for the professional motocross racer cc motors
•Consistent power delivery with an extended chain life
SYSTEMS •Ideal for race applications between 125-500cc •Chains include clip connecting link
•Chains include clip connecting link
420 CHAINS
ELECTRICAL
NUMBER OF LINKS HEAVY DUTY (GOLD) HEAVY DUTY (NATURAL) MXZ (STANDARD) NUMBER OF LINKS HEAVY DUTY (GOLD) HEAVY DUTY (NATURAL) MXZ (STANDARD)
78 1221‑0231 ‑ 1221‑0179 114 RK420MXZ114 1220‑0339 ‑
82 RK420MXZ82 ‑ 1221‑0180 116 RK420MXZ116 1220‑0340 ‑
LIGHTING 84 1221‑0233 ‑ 1221‑0181 118 RK420MXZ118 ‑ 1221‑0185
86 1221‑0234 ‑ 1221‑0182 120 RK420MXZ120 1220‑0341 ‑
96 RK420MXZ96 1220‑0346 ‑ 124 RK420MXZ124 1220‑0342 ‑
RIDER 100 RK420MXZ100 ‑ ‑ 126 RK420MXZ126 1220‑0343 ‑
ACCESSORIES 104 RK420MXZ104 1220‑0337 ‑ 130 RK420MXZ130 1220‑0344 ‑
108 1221‑0235 ‑ 1221‑0183 132 RK420MXZ132 1220‑0345 ‑
110 RK420MXZ110 1220‑0338 ‑ 136 1221‑0237 ‑ 1221‑0186
HARDWARE & 112 1221‑0236 ‑ 1221‑0184 140 1221‑0238 ‑ 1221‑0187

MERCHANDISING 420 CONNECTING LINKS
DESCRIPTION HEAVY DUTY (GOLD) HEAVY DUTY (NATURAL)
Clip connecting link R18422MXZ 1225‑0333
INDEX
SEE OUR SPROCKET AND CHAIN CONFIGURATOR AT HTTP://CHAINKIT.PARTSEUROPE.EU FOR A COMPLETE LIST OF FITMENTS.
382 2017 PARTS EUROPE ATV/UTV All part numbers in BOLD MAGENTA
are new this year.
