BELTS, CHAINS & SPROCKETS

JT DRIVE CHAIN (CONT) EXHAUST

428 CHAINS PLOWS &
LINKS HDR (NATURAL) PART # LINKS HDR (NATURAL) PART # IMPLEMENTS
100 1220‑0141 126 1220‑0152
112 1220‑0145 130 1220‑0154
120 1220‑0149 134 1220‑0156 WINCHES &
MOUNTS
428 CONNECTING LINKS
DESCRIPTION HDR (NATURAL) PART #
Clip link 1225‑0234 AUDIO &
VIDEO
520 CHAINS
LINKS HDR (NATURAL) PART # HDS (NATURAL) PART # X1R2 (NATURAL) PART # X1R2 (NICKEL) PART # Z3 (STEEL) PART # Z3 (NICKEL) PART #
36 ‑ ‑ 1223‑0821 ‑ ‑ ‑ GENERAL
74 ‑ ‑ 1223‑0822 ‑ ‑ ‑ ACCESSORIES
78 ‑ ‑ 1223‑0823 ‑ ‑ ‑
84 ‑ ‑ 1223‑0824 1223‑1133 ‑ ‑
86 ‑ ‑ 1223‑0825 1223‑1134 ‑ ‑ RACKS &
90 ‑ ‑ 1223‑0826 1223‑1135 ‑ ‑ ACCESSORIES
92 ‑ ‑ 1223‑0827 ‑ ‑ ‑
94 1220‑0174 ‑ 1223‑0828 ‑ ‑ ‑ TRUNKS,
96 1220‑0175 ‑ 1223‑0829 ‑ ‑ ‑ LUGGAGE &
98 1220‑0176 ‑ 1223‑0830 ‑ ‑ ‑ STORAGE
100 1220‑0177 ‑ 1223‑0831 1223‑1136 ‑ ‑
102 1220‑0178 1220‑0205 1223‑0832 ‑ 1223‑1054 ‑
104 1220‑0179 1220‑0206 1223‑0833 1223‑1137 1223‑1055 ‑ BODY
106 1220‑0181 ‑ 1223‑0834 1223‑1138 1223‑1056 1223‑1087
108 1220‑0182 1220‑0208 1223‑0835 1223‑1139 1223‑1057 ‑
110 1220‑0183 1220‑0209 ‑ 1223‑1140 1223‑1058 1223‑1089
112 1220‑0184 1220‑0210 ‑ 1223‑1141 1223‑1059 1223‑1090 ARMOR
114 1220‑0185 1220‑0211 1223‑0591 1223‑1142 1223‑1060 1223‑1091
116 1220‑0186 1220‑0212 1223‑0592 1223‑1143 1223‑1061 1223‑1092
118 1220‑0187 1220‑0213 1223‑0593 ‑ 1223‑1062 ‑ HANDLEBARS
120 1220‑0188 1220‑0214 1223‑0594 1223‑1144 1223‑1063 1223‑1094 & CONTROLS
124 1220‑0189 1220‑0215 1223‑0595 1223‑1145 1223‑1064 ‑

520 CONNECTING LINKS WHEEL
DESCRIPTION HDR (NATURAL) PART # HDS (NATURAL) PART # X1R2 (NATURAL) PART # Z1R (NATURAL) PART # Z3 (NATURAL) PART # Z3 (NICKEL) PART # X1R (NICKEL) PART # ACCESSORIES
Rivet link 1225‑0237 1225‑0241 1225‑0245 1225‑0332 1225‑0456 1225‑0455 1225‑0465
Clip link 1225‑0238 1225‑0242 1225‑0246 ‑ ‑ ‑ 1225‑0466
BRAKES
525 CHAINS
LINKS X1R (NATURAL) PART # Z3 (STEEL) PART # Z3 (NICKEL) PART # LINKS X1R (NATURAL) PART # Z3 (STEEL) PART # Z3 (NICKEL) PART #
104 ‑ ‑ ‑ 116 1223‑0450 1223‑1070 1223‑1101
106 ‑ 1223‑1065 ‑ 118 1223‑0451 1223‑1071 1223‑1102 BELTS, CHAINS
& SPROCKETS
108 1223‑0446 1223‑1066 1223‑1097 120 1223‑0452 1223‑1072 1223‑1103
110 1223‑0447 1223‑1067 1223‑1098 122 1223‑0453 ‑ ‑
112 1223‑0448 1223‑1068 1223‑1099 124 1223‑0454 ‑ ‑
114 1223‑0449 1223‑1069 1223‑1100 DRIVETRAIN

525 CONNECTING LINKS
DESCRIPTION X1R (NATURAL) PART # X1R (NATURAL) PART # DESCRIPTION X1R (NATURAL) PART # X1R (NATURAL) PART #
Rivet link 1225‑0249 1225‑0331 Clip link 1225‑0250 ‑ SUSPENSION

530 CHAINS
LINKS X1R (NATURAL) PART # Z3 (STEEL) PART # Z3 (NICKEL) PART #
94 1223‑0494 ‑ ‑ ENGINE
96 1223‑0495 ‑ ‑
98 1223‑0496 ‑ ‑
100 1223‑0497 ‑ ‑ FUEL/AIR
102 1223‑0498 1223‑1074 ‑ SYSTEMS
104 1223‑0499 1223‑1075 ‑
106 1223‑0500 1223‑1076 1223‑1107
108 1223‑0501 1223‑1077 1223‑1108
110 1223‑0502 1223‑1078 1223‑1109 ELECTRICAL
112 1223‑0503 1223‑1079 1223‑1110
114 1223‑0504 1223‑1080 1223‑1111
116 1223‑0505 1223‑1081 1223‑1112 LIGHTING
118 1223‑0506 1223‑1082 1223‑1113
120 1223‑0507 1223‑1083 1223‑1114

530 CONNECTING LINKS RIDER
DESCRIPTION X1R (NATURAL) PART # Z1R (NATURAL) PART # DESCRIPTION X1R (NATURAL) PART # Z1R (NATURAL) PART # ACCESSORIES
Rivet link 1225‑0253 1225‑0330 Clip link 1225‑0254 ‑

HARDWARE &
MERCHANDISING

INDEX
SEE OUR SPROCKET AND CHAIN CONFIGURATOR AT HTTP://CHAINKIT.PARTSEUROPE.EU FOR A COMPLETE LIST OF FITMENTS.
