MURDOCK RISERS
•Investment-cast steel one-piece top clamp
1
•TIG welded 0,120” wall 4130 chromoly steel uprights with /2”-13
ENGINE •Available in 15 cm; 20,5 cm and 25,5 cm rises (6”, 8” and 10”)
•Satin black electroplated or polished show chrome
•Handlebar clamp bolt patterns fit speedo/ tach brackets on many stock model year Harleys 0602-0661
PART # DESCRIPTION PART # DESCRIPTION
TRANSMISSION POLISHED BLACK
& DRIVELINE 0602‑0760 10 cm tall (4”) 0602‑0761 10 cm tall (4”)
0602‑0659 15 cm tall (6”) 0602‑0660 15 cm tall (6”)
0602‑0661 20,5 cm tall (8”) 0602‑0662 20,5 cm tall (8”)
0602‑0663 25,5 cm tall (10”) 0602‑0664 25,5 cm tall (10”)
GASKETS 0602‑0762 30,5 cm tall (12”) 0602‑0763 30,5 cm tall (12”)
& SEALS 0602‑0764 35,5 cm tall (14”) 0602‑0765 35,5 cm tall (14”) 0602-0763

ELECTRICAL
& LIGHTING

HANDLEBARS,
CONTROLS & 51 MM (2”) THUNDER RISERS 0602-0569
MIRRORS •Investment-cast stainless steel construction
•Fit bars with 25,4 mm diameter (1”) in clamping area
3
•11 cm wide (4 /8”) with 51 mm rise (2”) 0602-0570
1
•89 mm (3 /2”) on-center mounting holes accept /2” x 13
1
CABLES mounting hardware
•Include stainless top clamp hardware
•Available in raw polished or black electroplated finish
PART # DESCRIPTION PART # DESCRIPTION
0602‑0569 Raw polished 0602‑0570 Black electroplate
BRAKES
OIL TANKS,
FILTERS &
GAS TANKS

3
44 MM (1 /4”) SLIMLINE RISERS
DASHES
& GAUGES •Investment-cast stainless steel construction
•Fit bars with 25,4 mm diameter (1”) in clamping area 0602-0567
•Low profile 44 mm rise (1,75”)
1
CHASSIS, •Bottom clamps accept stock /2” x 13 mounting hardware 0602-0568
5
SUSPENSION, • /16” -18 stainless steel Allen cap handlebar clamp screws
FENDERS •Available in raw polished or black electroplate finish
& WHEELS •Sold in pairs
PART # DESCRIPTION PART # DESCRIPTION
0602‑0567 Raw polished 0602‑0568 Black electroplate
FLOORBOARDS
& PEGS
HARDWARE
BRASS HANDLEBAR RISERS
•Solid brass construction
•Polished finish
1
•Drilled and tapped for /2”-13 mounting bolts (sold separately)
GENERAL •For bars with 25,4 mm (1”) diameter clamping area
•Sold in pairs PART # DESCRIPTION
•Made in the U.S.A. 0602‑0557 38 mm (1,5”) tall brass risers
