IRONHEAD XL

0602‑0513
GLIDE SEATS &
STYLE RISERS SISSY BARS
•Manufactured from
6061 T‑6 aluminum and
chrome plated
•For 25,4 mm (1”) EXHAUST
diameter handlebars
1
•Require /2”‑13 mounting bolts
•Made in the U.S.A.; sold in pairs DS290276
PART # DESCRIPTION CARBURETORS
0602‑0515 DS290275 51 mm (2”) & AIR FILTERS
0602‑0514 DS290276 10 cm (4”)

ENGINE

COPED HANDLEBAR
BRASS HANDLEBAR RISERS RISER BUNGS TRANSMISSION
•Made from CNC‑machined billet solid brass •These are coped, threaded bungs for & DRIVELINE
•Feature a brushed machine finish making custom handlebars 0502‑0467
1
•Fit 25,4 mm (1”) handlebars •Tapped for /2”‑20 fine thread
•Sold in pairs •They give 25,4 mm (1”) of rise from the flat end to the bottom of the
•Made in the U.S.A. coped section GASKETS
7
PART # DESCRIPTION •Available for 22 mm ( /8”) or 25,4 mm (1”) handlebar construction & SEALS
0602‑0513 10 cm (4”) Glide‑style risers w/ thru‑hole •Sold in pairs
0602‑0514 76 mm (3”) Post‑style risers •Made in the U.S.A.
0602‑0515 12,5 cm (5”) offset Post‑style risers PART # DESCRIPTION
0502‑0467 For 22 mm ( 7 /8”) handlebar construction; 22 mm dia. (0,875”) ELECTRICAL
0502‑0458 For 25,4 mm (1”) handlebar construction; 25,4 mm dia. (1,00”) & LIGHTING
DS‑222055
HANDLEBARS,
CONTROLS &
®
NESS TECH MIRRORS
HANDLEBAR RISER
BUSHING KITS
HANDLEBAR DAMPER KIT •Kits include polished 303 CABLES
stainless steel custom
•Replacement damper kit includes one pair of dampers and four washers, polyurethane
chrome cup washers bushings, bushing inserts
•Meets or exceeds OEM specifications and Allen head bolts
PART # DESCRIPTION •Available in fine‑ or coarse‑thread applications BRAKES
DS‑222055 For 73‑E84 XL; repl. OEM #s 56153‑73, 56158‑73, 56159‑73 •Made in the U.S.A.
DS‑222059 Repl. chrome washers only (4‑pk.) PART # DESCRIPTION
1611‑0498 1 /2”‑20 OIL TANKS,

FILTERS &
GAS TANKS

DASHES
POLYURETHANE RISER & GAUGES
BUSHING KIT
GOODEN TIGHT™ RISER BUSHING KITS •Adds a more positive feel to handlebars CHASSIS,
•Revolutionary design reduces vibration better than any other riser •Limits vibrations SUSPENSION,
bushing on the market •Kit contains high‑quality bushings, FENDERS
•Sold in sets of four chrome handlebar retainer washers and & WHEELS
•Made in the U.S.A. steel inner sleeves
U.S. Patent #6,547,269. •Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION FLOORBOARDS
0602‑0005 For 73‑85 XL DS‑290571 For 73‑85 XL w/ unthreaded risers & PEGS

HARDWARE

HANDLEBAR DAMPER KIT
•Faithful reproduction of the late‑style handlebar damper kit
•Includes two studs, two rubber damper sets and four zinc‑plated cup washers GENERAL
PART # DESCRIPTION
DS‑222054 For L84‑85 XL; repl. OEM #s 56105‑84, 56158‑73, 56159‑73

ALL PART NUMBERS IN BLUE ARE NEW 671
