Page 98 - Oldbook 2017

SHOVELHEAD

SEATS &
SISSY BARS

TRANSMISSION DOOR BEARINGS
•Sold in pairs
EXHAUST TRANSMISSION BEARINGS 1106‑0034 1106‑0003 •Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION
1106‑0034 Clutch side mainshaft bearing for 80‑83 Shovelhead 5‑speed; repl. OEM #8978 DS‑197063 For 80‑83 Shovelhead
1106‑0003 Countershaft needle bearing L76‑84 Shovelhead 4‑speed; repl OEM #33961‑52 5‑speeds; repl. OEM #8998
CARBURETORS
& AIR FILTERS

ENGINE TRANSMISSION LOCK TAB
WASHERS AND SNAP RINGS
•During transmission work, replace the
lock tab washers and snap rings
TRANSMISSION •Fit a variety of Shovelhead applications;
& DRIVELINE sold in 10‑pack (unless noted) 0950‑0416 DS‑194396 DS‑188018
PART # DESCRIPTION MFG.
LOCK TAB WASHERS
0950‑0415 Starter clutch, 66‑84 Shovelhead 4‑sp.; repl. OEM #33396‑39 Eastern MC Parts
GASKETS 0950‑0416 Starter crank and countershaft, 66‑84 Shovelhead 4‑sp.; repl. OEM #33082‑16 Eastern MC Parts
& SEALS 0950‑0417 Mainshaft, 66‑84 Shovelhead 4‑sp.; repl. OEM #35050‑40 Eastern MC Parts
0950‑0412 Shift fork, 66‑79 Shovelhead 4‑sp.; repl. OEM #34180‑33 Eastern MC Parts
0950‑0413 Countershaft sprocket, 66‑83 Shovelhead 4‑sp.; repl. OEM #35216‑36 Eastern MC Parts
0935‑0094 Countershaft sprocket, 66‑83 Shovelhead 4‑sp. (5‑pk.); repl. OEM #35216‑36 Genuine James
ELECTRICAL DS‑194396 Inner primary, 80‑83 Shovelhead; repl. OEM #7402 Eastern MC Parts
& LIGHTING 1106‑0019 Cam follower spring lock tab, 66‑82 Shovelhead; repl. OEM #34066‑52 Eastern MC Parts
SNAP RINGS
DS‑188023 Shifter cam 5‑speed, all 80‑83 Shovelhead; repl. OEM #11083 Eastern MC Parts
HANDLEBARS, DS‑188018 Shifter fork shaft, 66‑84 Shovelhead; repl. OEM #11036 Eastern MC Parts
CONTROLS &
MIRRORS
SHIFTER ARM SHIFTER ARM
ADJUSTING SCREW ADJUSTING SCREW
CABLES •High‑quality OEM •Hardened to 47‑49 Rockwell
replacement component •Sold each
•Sold each •Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION
1110‑0044 For 80‑83 Shovelhead 5‑speed (OB); repl. OEM #33119‑79A/B DS194067 For 80‑83 Shovelhead 5‑speeds; repl. OEM #33119‑79A/B
BRAKES

OIL TANKS,
FILTERS &
GAS TANKS
TRANSMISSION
TRANSMISSION VENT COVER ALIGNMENT MOUNT
DASHES •Chrome cover that offers a unique custom look •Provides an inexpensive way to
& GAUGES •Eliminates OEM rubber vent hose on top align and keep the transmission in
of transmission place when running a belt drive
•Installs in minutes with included instructions •Made of 1” x 1” billet aluminum
CHASSIS, •Fits 5‑ and 6‑speed transmissions with OEM top vent hose •Made in U.S.A.
SUSPENSION,
FENDERS PART # DESCRIPTION PART # DESCRIPTION
& WHEELS 1105‑0007 For 5‑ and 6‑speed Big Twin transmissions 0933‑0073 For 66‑84 Shovelhead

FLOORBOARDS
& PEGS

HARDWARE
TRANSMISSION MOUNTING PLATE
•Heavy‑duty steel construction; chrome finish
•Easy bolt‑in application
GENERAL •Made in the U.S.A.
PART # DESCRIPTION
1105‑0011 For 66‑84 Paughco rigid and 4‑speed Shovelhead swingarm frames; repl. OEM #s 47968‑36, 47698‑65

96 ALL PART NUMBERS IN BLUE ARE NEW
