SHOVELHEAD

3
SEATS &
11 SISSY BARS
1 6
2 2A 8
9
5
4 10 EXHAUST
12
7 13
8
14
11
5 5 CARBURETORS
5 11 & AIR FILTERS
15
MAINSHAFTS AND COMPONENTS FOR 5-SPEED SHOVELHEAD 16 17
•Sold individually unless noted
NOTE: For complete gear sets see page 91 ENGINE
FOR 80-83 SHOVELHEAD
REF # PART # OEM # DESCRIPTION MFG.
(1) DS-193148 35078-79 Nylock nut, 80-83 (10-pk.) Eastern TRANSMISSION
(2) DS-193149 35076-79 Spacer, 80-83 (10-pk.) Eastern
(2A) DS-197063 8998 Bearing, 80-83 (pr.) JIMS & DRIVELINE
(3) DS-188057 35021-89 Retaining ring, 80-83 Eastern
(4) DS-199455 35028-79A 4th gear, mainshaft, 80-83 (10-pk.) Andrews
(5) DS-194280 6003 Thrust washer, 80-83 (5-pk.) Eastern
(6) DS-199480 35025-79B 1st gear, mainshaft, 80-83 JIMS GASKETS
(6) 1106-0060 35025-79 1st gear, mainshaft, 80-83 Andrews & SEALS
(7) DS-199531 - 1st gear set, 80-83 (close ratio 2,94) Andrews
(8) DS-189705 8876A Mainshaft/ countershaft bearing, 80-83 Sonnax
(9) DS-199490 35042-79 Mainshaft, 80-83 JIMS
(9) 1106-0061 35042-79 Mainshaft, 80-83 Andrews ELECTRICAL
(10) DS-194360 37523-15 Clutch hub key, 80-83 (10-pk.) Eastern & LIGHTING
(11) DS-188022 11067 Main and countershaft snap rings, 80-83 (10-pk.) Eastern
(12) DS-199486 35027-79B 3rd gear, mainshaft, 80-83 JIMS
(12) DS-199451 35027-79A 3rd gear, mainshaft, 80-83 Andrews
(13) DS-199483 35026-79C 2nd gear, mainshaft, 80-83 JIMS HANDLEBARS,
(13) DS-199450 35026-79B 2nd gear, mainshaft, 80-83 Andrews CONTROLS &
(14) DS-199452 35029-79 Main drive gear, 80-E84 w/ chain drive Andrews MIRRORS
(15) 1106-0039 8904 Needle bearing, 5th gear mainshaft, 80-83 Drag Specialties
(16) DS-174475 12013A Oil seal, L81-83 (5-pk.) Genuine James
(17) 1106-0034 8978 Bearing, 80-83 FLT Eastern

CABLES
1
2
2A 4
3 5
BRAKES
6 7 8 9 8
10 OIL TANKS,
FILTERS &
11 GAS TANKS
7 6 12
COUNTERSHAFT AND COMPONENTS
FOR 5-SPEED SHOVELHEAD 7 DASHES
•Sold individually, unless noted 13 & GAUGES
NOTE: For complete gear sets see page 91
FOR 80-83 SHOVELHEAD CHASSIS,
REF # PART # OEM # DESCRIPTION MFG. SUSPENSION,
(1) DS-193148 35078-79 Nylock nut, 80-83 (10-pk.) Eastern FENDERS
(2) DS-193149 35076-79 Spacer, 80-83 (10-pk.) Eastern & WHEELS
(2A) DS-197063 8998 Bearing, 80-83 (pr.) JIMS
(3) DS-188057 35021-89 Retaining ring, 80-83 (10-pk.) Eastern
(4) DS-199484 35625-79B 4th gear, countershaft, 80-83 JIMS FLOORBOARDS
(4) DS-199456 35625-79B/ 35625-79/ 35628-79 4th gear, countershaft, 80-83 Andrews & PEGS
(5) 1106-0059 35622-79A 1st gear, countershaft, 80-83 Andrews
(5) DS-199481 35622-79C 1st gear, countershaft, 80-83 JIMS
(6) DS-194280 6003 Thrust washer, 80-83 (5-pk.) Eastern
(7) DS-188022 11067 Retaining ring, 80-83 (10-pk.) Eastern HARDWARE
(8) DS-189705 8876A Mainshaft/ countershaft bearing, 80-83 Sonnax
(9) DS-199423 35632-79 Countershaft, 80-83 Andrews
(10) DS-199450 35026-79B 3rd gear, countershaft, 80-83 Andrews
(11) DS-199486 35027-79B 2nd gear, countershaft, 80-83 JIMS
(11) DS-199451 35027-79B 2nd gear, countershaft, 80-83 Andrews
(12) DS-199485 35626-79B 5th gear, countershaft, 80-83 JIMS GENERAL
(12) DS-199453 35626-79B 5th gear, countershaft, 80-83 Andrews
(13) DS-189708 8977 Countershaft bearing, left side, 80-83 Sonnax

ALL PART NUMBERS IN BLUE ARE NEW 93
