SHOVELHEAD

SEATS &
SISSY BARS
DS-904204
DS905808 EXHAUST

BARE BONES SOLO SEATS CARBURETORS
•Simplistic style brings out the true expression of your & AIR FILTERS
custom or stock bike
•Top-grade black vinyl cover
•Base plate is powder-coated steel and carpeted to protect
painted surfaces ENGINE
•Available with or without Biker Gel Pad
•Pillion pad sold separately
•Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION TRANSMISSION
FOR 82‑83 FXR FOR 82‑83 FXR (CONT) FOR 82‑83 FXR (CONT) & DRIVELINE
DS905807 Smooth solo seat w/ Biker Gel DS‑904204 Smooth solo seat DS905808 Smooth pillion pad; 16 cm W (6 /4”)
1

GASKETS
& SEALS

ELECTRICAL
& LIGHTING

HANDLEBARS,
CONTROLS &
MIRRORS

CABLES

BRAKES

OIL TANKS,
FASTBACK SEAT REGAL DUKE PILLOW SEAT FILTERS &
•Offers a super-clean, custom style, cut low for the rider with good •Split foam construction on a single steel base plate GAS TANKS
back support •Well-padded and features a leather-like expanded vinyl covering
•Offers a reasonable degree of passenger comfort •Designed to keep driver from sliding forward
•Top covering made of highest-quality expanded vinyl •Made in the U.S.A.
•Made in the U.S.A. PART # DESCRIPTION DASHES
& GAUGES
PART # DESCRIPTION FOR 82‑83 FXR
FOR 82‑83 FXR DS‑900385 Regal Duke 2-piece design seat;
0805‑0053 Fastback seat; 30,5 cm W (12”) front; 18 cm W (7”) rear 33 cm W (13”) front; 21,5 cm W (8,5”) rear CHASSIS,
SUSPENSION,
FENDERS
& WHEELS

FLOORBOARDS
& PEGS

VINTAGE STYLE SEAT HARDWARE
•Front bucket is trimmed with a functional skirt that comes down over
the frame and fender for a clean, uninterrupted look
•Studded Naugahyde cover is trimmed with conchos tied with leather
•Made from highest quality expanded vinyl
•Passenger seat angles forward to support the rider’s back PART # DESCRIPTION GENERAL
•Built on a single-piece steel base that fits like stock FOR 82‑83 FXR
•Made in the U.S.A. 0805‑0055 Vintage, wide style 40,5 cm W (16”) front; 30,5 cm W (12”) rear

ALL PART NUMBERS IN BLUE ARE NEW 7
