IRONHEAD XL

SEATS &
SISSY BARS

LEGACY GAS TANK
•Precision-made tanks are TIG-welded construction using deep-drawn steel EXHAUST
•Unique, functional styling gives the bike a great custom look
•All styles hold approximately 14,4 liters (3,8 gallons) and are pressure-tested
•Include stock screw-in gas cap bung (gas cap sold separately; use L96-15 style cap)
•Install using stock mounts
•Has left- and right-hand 22 mm threaded petcock bungs and includes a steel CARBURETORS
block-off cap & AIR FILTERS
PART # DESCRIPTION
0701‑0762 For 83-85 XL (repl. OEM #s 61023-93, 61348-96A)

ENGINE

TRANSMISSION
& DRIVELINE

GASKETS
& SEALS

ELECTRICAL
EXTENDED DASH-STYLE & LIGHTING
®
RUBBER-MOUNT QUICKBOB TANK KIT
•Fully functional extended design, 51 mm (2”) longer than a standard
Quickbob tank HANDLEBARS,
•Allows the lines of the tank to flow into the lines of the seat CONTROLS &
for a great custom look MIRRORS
•Tanks have cutout in rear for seat nose (some seats may need
to be modified)
•Includes a three-light dash, dash base, 2:1 ratio speedo with trip reset (68-84 style
face), rubber dampener, a 6-post Fat Bob ignition switch and a screw-in gas cap CABLES
•All tanks come with necessary mounting brackets
•14,8 liter (3,9 US gal.) fuel capacity PART # DESCRIPTION
•Utilizes a 22 mm petcock DS‑391322 For 82-85 XL

BRAKES
DS-391351 DS-391352

OIL TANKS,
EXTENDED SMOOTH-TOP FILTERS &
®
QUICKBOB RUBBER- GAS TANKS
MOUNT GAS TANKS
•Extended design of these tanks
allows the lines of the tank to flow DASHES
into the lines of the seat for a great & GAUGES
custom look
•51 mm (2”) longer than a standard CHASSIS,
QuickBob tank
•Available in a single or dual gas SUSPENSION,
cap style FENDERS
•Tanks have cutout in rear for seat nose & WHEELS
(some seats may need to be shortened)
•Feature screw-in bungs (use 82-E96 FLOORBOARDS
style caps)
•14,8 liter (3,9 US gal.) capacity & PEGS
•Utilize a 22 mm petcock
•Each tank comes with necessary
mounting brackets
•Requires PART #DS-390077 ignition coil DS-390077 HARDWARE
relocation kit; sold separately
PART # DESCRIPTION PART # DESCRIPTION
FOR 82‑85 XL FOR 82‑85 XL (CONT)
DS‑391351 Twin-cap style gas tank DS‑390077 Ignition relocation kit
DS‑391352 Single-cap style gas tank GENERAL

WARNING: All tanks are shipped unpainted. Caps are not included unless noted. All gas tanks should be fitted, pressure-tested and sealed
BEFORE being painted to eliminate potential problems.
707
ALL PART NUMBERS IN BLUE ARE NEW
