ELECTRICAL BYO BUILD-YOUR-OWN
& LIGHTING BRAKE LINE BUILDER KITS
•Assemble lines in only 5 minutes with side cutters and
7
a /16” wrench for perfect fit and alignment every time
HANDLEBARS, •Two different kits are available in black and chrome to solve your brake line
CONTROLS & assembly challenges
MIRRORS •Deluxe Builder Kits contain banjos and fittings to build multiple front single disc brake lines,
hydraulic clutch lines and most rear brake lines
•Master Builder Kits include everything in the Deluxe Kits, plus additional banjos along with four brazed and
plated manifolds to build most dual front disc brake lines
CABLES •All kits are organized in a labeled, compartmental carrying case and include 7,6 m (25’) of non-yellowing
clear or black coated braided stainless steel hose, chrome or black chrome plated banjos, polished stainless
hardware, copper crush washers plus a set of durable Aluminum BYO Vise Jaws
®
•Kit contents are listed below
•Brake hose and fittings are compliance labeled, pressure tested and 100% inspected
BRAKES •Patented design meets all FMV55-106 standards once assembled per the included instructions for safe and
reliable on-road use
•Replacement multi-packs components also available
®
NOTE: BYO brand brake hose and components have been specifically designed to work ONLY in conjunction 3850-0229
OIL TANKS, with each other. Use with any other Magnum brake line products or other manufacturer’s brands will
FILTERS & NOT pass FMVSS-106 criteria and will void all warranty, performance, and liability claims.
GAS TANKS
PART # DESCRIPTION
CHROME
1742‑0412 Deluxe Builder Kit
DASHES 1742‑0413 Master Builder Kit
& GAUGES BLACK
1742‑0415 Deluxe Builder Kit
1742‑0416 Master Builder Kit
CHASSIS, REPLACEMENT COMPONENTS
SUSPENSION, 1742‑0408 3 /8” copper crush washer (10-pk.)
FENDERS 1742‑0409 7 /16” copper crush washer (10-pk.)
& WHEELS 1742‑0410 12 mm copper crush washer (10-pk.)
1742‑0417 3 /8”-24 inverted flare fitting (3-pk.)
1742‑0418 3 /8” 180° banjo, chrome (3-pk.)
FLOORBOARDS 1742‑0419 3 /8” 35° banjo, chrome (3-pk.)
& PEGS 1742‑0420 3 /8” 60° banjo, chrome (3-pk.)
1742‑0421 3 /8” 90° banjo, chrome (3-pk.)
1742‑0422 7 /16” 180° banjo, chrome (3-pk.)
1742‑0423 7 /16” 35° banjo, chrome (3-pk.)
HARDWARE 1742‑0424 7 /16” 90° banjo, chrome (3-pk.)
1742‑0425 3 /8” 180° banjo, black (3-pk.)
1742‑0426 3 /8” 35° banjo, black (3-pk.)
1742‑0427 3 /8” 60° banjo, black (3-pk.)
1742‑0428 3 /8” 90° banjo, black (3-pk.)
1742‑0429 7 /16” 180° banjo, black (3-pk.)
GENERAL 1742‑0430 7 /16” 35° banjo, black (3-pk.)
1742‑0431 7 /16” 90° banjo, black (3-pk.)
3850‑0229 BYO ® Aluminum Vise Jaws
