Page 701 - Oldbook 2017

IRONHEAD XL

DS098151
1742-0046 SEATS &
DS098147 DS098150 1742-0045 SISSY BARS
DS098154
DS098152 DS098153
1742-0047 DS098300 DS098301 EXHAUST
DS098279
DS098302 DS098633 DS098396 DS098244
Black vinyl CARBURETORS
brake line & AIR FILTERS

DS098281 DS098283 DS098380 DS098293
DS098282
DS098290 DS098291
ENGINE
Stainless steel DS098298 1204-2724
brake lines
DS098296
UNIVERSAL BRAKE LINES 1742-0049 TRANSMISSION
AND CHROME FITTINGS 1742-0048 & DRIVELINE
•Top-quality stainless steel brake lines or black
vinyl-coated stainless steel/ braided brake lines,
banjo bolts, brake line fittings and GASKETS
crush washers provide consistent, & SEALS
reliable performance 1742-0058
•Lines are available in 23 cm through 203 cm 1204-2725 1742-0050
(9” through 80”) lengths and are clear-coated DS098117
•Feature chrome-plated AN-3 ends 1742-0044 ELECTRICAL
•Banjo bolts and fittings are chrome-plated & LIGHTING
and sold separately 1204-2723
•Made in the U.S.A. DS098109 DS098105
STAINLESS STEEL BRAKE LINES
HANDLEBARS,
PART # LENGTH PART # LENGTH PART # LENGTH PART # LENGTH PART # LENGTH PART # LENGTH CONTROLS &
DS098809 23 cm (9”) DS098819 48,5 cm (19”) DS098828 71 cm (28”) DS098843 109 cm (43”) DS098856 142 cm (56”) 1204-2732175 cm (69”) MIRRORS
1204-272625,4 cm (10”) 1204-272951 cm (20”) DS098830 76 cm (30”) DS098844 112 cm (44”) DS098858 147 cm (58”) DS098870 178 cm (70”)
DS098812 30,5 cm (12”) DS098821 53,5 cm (21”) DS098832 81 cm (32”) DS098845 114 cm (45”) DS098860 152 cm (60”) 1204-2733180 cm (71”)
1204-272735,5 cm (14”) 1204-273056 cm (22”) DS098834 86 cm (34”) DS098846 117 cm (46”) DS098861 155 cm (61”) DS098872 183 cm (72”)
DS098815 38 cm (15”) DS098823 58,5 cm (23”) DS098836 91 cm (36”) DS098847 119 cm (47”) DS098862 157 cm (62”) DS098874 188 cm (74”) CABLES
1204-272840,5 cm (16”) 1204-273161 cm (24”) DS098838 97 cm (38”) DS098850 127 cm (50”) DS098864 163 cm (64”) DS098876 193 cm (76”)
DS098817 43 cm (17”) DS098825 63,5 cm (25”) DS098840 102 cm (40”) DS098852 132 cm (52”) DS098866 168 cm (66”) DS098878 198 cm (78”)
DS098818 45,5 cm (18”) DS098826 66 cm (26”) DS098842 107 cm (42”) DS098854 137 cm (54”) DS098868 173 cm (68”) DS098880 203 cm (80”)

BLACK VINYL-COATED STAINLESS STEEL BRAKE LINES
BRAKES
PART # LENGTH PART # LENGTH PART # LENGTH PART # LENGTH PART # LENGTH PART # LENGTH
1741-2700 23 cm (9”) 1741-2708 48,5 cm (19”) 1741-2716 71 cm (28”) 1741-2724 109 cm (43”) 1741-2732 142 cm (56”) 1741-2740 175 cm (69”)
1741-2701 25,4 cm (10”) 1741-2709 51 cm (20”) 1741-2717 76 cm (30”) 1741-2725 112 cm (44”) 1741-2733 147 cm (58”) 1741-2741 178 cm (70”)
1741-2702 30,5 cm (12”) 1741-2710 53,5 cm (21”) 1741-2718 81 cm (32”) 1741-2726 114 cm (45”) 1741-2734 152 cm (60”) 1741-2742 180 cm (71”) OIL TANKS,
1741-2703 35,5 cm (14”) 1741-2711 56 cm (22”) 1741-2719 86 cm (34”) 1741-2727 117 cm (46”) 1741-2735 155 cm (61”) 1741-2743 183 cm (72”) FILTERS &
1741-2704 38 cm (15”) 1741-2712 58,5 cm (23”) 1741-2720 91 cm (36”) 1741-2728 119 cm (47”) 1741-2736 157 cm (62”) 1741-2744 188 cm (74”) GAS TANKS
1741-2705 40,5 cm (16”) 1741-2713 61 cm (24”) 1741-2721 97 cm (38”) 1741-2729 127 cm (50”) 1741-2737 163 cm (64”) 1741-2745 193 cm (76”)
1741-2706 43 cm (17”) 1741-2714 63,5 cm (25”) 1741-2722 102 cm (40”) 1741-2730 132 cm (52”) 1741-2738 168 cm (66”) 1741-2746 198 cm (78”)
1741-2707 45,5 cm (18”) 1741-2715 66 cm (26”) 1741-2723 107 cm (42”) 1741-2731 137 cm (54”) 1741-2739 173 cm (68”) 1741-2747 203 cm (80”)
DASHES
PART # DESCRIPTION PART # DESCRIPTION & GAUGES
FITTINGS FITTINGS (CONT)
DS098147 3 /8” banjo x AN-3 male straight DS098293 AN-3 x 1 /8” NPT male 45°
DS098150 3 /8” banjo x AN-3 male 35° DS098290 3 /8”-24 inverted flare front brake junction CHASSIS,
DS098151 3 /8” banjo x AN-3 male 90° DS098291 1 /8” NPT front brake junction SUSPENSION,
DS098152 7 /16” banjo x AN-3 male straight DS098298 AN-3 male tee FENDERS
DS098153 7 /16” banjo x AN-3 male 35° DS098296 3 /8”-24 dual disc tee & WHEELS
DS098154 7 /16” banjo x AN-3 male 90° 1742-0048 Wide glide front brake tee
1742-0045 3 /8” banjo x AN-3 male 35° short w/ brake light switch mount 1742-0049 Narrow glide front brake tee
1742-0046 3 /8” banjo x AN-3 male 90° short w/ brake light switch mount 1204-2724 Universal rear brake tee w/ block and brake light switch hole FLOORBOARDS
1742-0047 3 /8” banjo x AN-3 male 90° long w/ brake light switch mount 1204-2725 Rear brake tee w/ brake light switch hole & PEGS
DS098300 3 /8” banjo x /8” NPT 35° w/ brake light switch mount 1742-0058 Universal rear brake tee w/ brake light switch hole
1
DS098301 3 /8” banjo x /8” NPT 90° short w/ brake light switch mount BANJO BOLTS
1
1
DS098302 3 /8” banjo x /8” NPT 90° long w/ brake light switch mount 1742-0044 3 /8”-24 banjo bolt w/ brake light switch mount
DS098633 AN-3 union DS098109 3 /8”-24 banjo bolt
DS098396 AN-3 male x 3 /8” inverted flare straight DS098117 3 /8”-24 dual banjo bolt HARDWARE
3
DS098244 AN-3 male x 1 /8” NPT male straight 1204-2723 3 /8”-24 banjo bolt ( /4” L minus head)
DS098279 AN-3 male x 1 /8” NPT male 90° DS098115 7 /16”-24 banjo bolt
DS098281 AN-3 male x 3 /8”-24 inverted flare 45° 1742-0050 7 /16”-24 banjo bolt with step-down to /8”
3
DS098282 AN-3 x 3 /8”-24 inverted flare 90° short CRUSH WASHERS
DS098283 AN-3 x 3 /8”-24 inverted flare 90° long DS098105 3 /8” crush washers (10-pk.) GENERAL
DS098284 AN-3 x 3 /8”-24 inverted flare 150° DS098106 7 /16” crush washers (10-pk.)
DS098380 AN-3 x 3 /8” inverted flare 90°-120°

ALL PART NUMBERS IN BLUE ARE NEW 699
