Page 637 - Oldbook 2017

IRONHEAD XL

SEATS &
SISSY BARS
UNIVERSAL
IGNITION SWITCH IGNITION SWITCH
•Chrome replacement ignition •Three-position switch (off/ EXHAUST
and light switch ignition/ ignition w/ lights)
•Three-position switches with sturdy, die-cast housing
•Includes two keys •Includes two keys and two threaded nuts for proper mounting
3
PART # DESCRIPTION •Requires a 19 mm ( /4”) diameter hole for mounting CARBURETORS
DS‑272114 For 79-85 XL; repl. OEM #71425-77 PART # DESCRIPTION & AIR FILTERS
40‑64000 Universal ignition switch

IGNITION
SWITCH ENGINE
CUSTOM ROUND KEY MOUNT
IGNITION SWITCH •Chrome-plated ignition switch mount
7
•Round key design with three- •Features a 22,2 mm ( /8”) hole that
position activation: off, ignition accepts most ignition switches TRANSMISSION
only, or ignition and lights •Mounts almost anywhere using an 8 mm & DRIVELINE
•Sold individually ( /16”) mounting hole
5
PART # DESCRIPTION PART # DESCRIPTION
DS‑272112 For 79-85 XL 2106‑0041 Ignition switch mount
GASKETS
& SEALS
0521-0889
m-LOCK DIGITAL IGNITION ELECTRICAL
LOCK AND ACCESSORIES & LIGHTING
•A digital ignition/ starter lock
•Replaces a mechanical ignition lock and its electrical switching function (on/ off) HANDLEBARS,
•The ignition and power supply of the bike is switched on when within 30 mm-50 mm CONTROLS &
of the digital key/ transponder
•Uses the most recent RFID technology (radio frequency identification) MIRRORS
•Each key is singular by its digital code and cannot be spoofed
•Includes one master key and one user key that are the size of a key tag
•Keys do not require batteries
•Additional or replacement keys can be purchased separately and “trained” to the m-Lock CABLES
•Optional “Glass Tube” key measures 3 mm x 13 mm
PART # DESCRIPTION PART # DESCRIPTION
0521‑0889 m-Lock digital ignition lock 2020‑0468 m-Lock teardrop key
2020‑0466 m-Lock 12V 50A relay 2020‑0469 m-Lock Glass Tube key BRAKES
2020‑0467 m-Lock back capacitor

OIL TANKS,
FILTERS &
GAS TANKS

HYDRAULIC 2106-0128 DASHES
STOPLIGHT SWITCHES 2106-0127 & GAUGES
•Feature Bakelite insulators, DS-272191 DS-272175 HYDRAULIC STOPLIGHT SWITCH
heavy-duty contacts and high- •Bakelite insulators, high-conductivity brass terminals
conductivity brass terminals and heavy-duty contacts CHASSIS,
PART # DESCRIPTION PART # DESCRIPTION SUSPENSION,
DS‑272191 Spade-type switch for 79-85 XL; repl. OEM #72023-51C 2106‑0128 Spade-type switch for 79-85 XL; OEM# 72023-51A FENDERS
DS‑272175 Screw-type switch for 77-78 XLCR; repl. OEM #72002-51A 2106‑0127 Screw-type switch for 77-78 XLCR; repl. OEM #72002-51A & WHEELS

DS-272174 FLOORBOARDS
& PEGS
DS-272171
STOPLIGHT
SWITCHES HARDWARE
•Chrome replacement
stoplight switches
•Also work great for STOPLIGHT SWITCH
custom applications •Replacement stoplight switch for
PART # DESCRIPTION front brake handlebar control GENERAL
DS‑272174 For 75-76 XL; repl. OEM #72004-75 PART # DESCRIPTION
DS‑272171 For 67-74 XL (push); repl. OEM #72004-70 DS‑272140 For 73-81 XL; repl. OEM #72001-69B

ALL PART NUMBERS IN BLUE ARE NEW 635
