IRONHEAD XL

SEATS &
SISSY BARS
DRAG SPECIALTIES
AGM MAINTENANCE-FREE BATTERIES
•Fillable batteries from Drag Specialties!
EXHAUST •Specifically designed for hard starting, high performance engines that need
extra cranking power
•Radial grid technology delivers higher cranking amps and superior performance
•Special-absorbed glass-mat battery eliminates water loss, permitting the battery
to be permanently sealed once it is filled with acid; Acid Pack included
CARBURETORS •Superior vibration resistance and durability provides a long service life
& AIR FILTERS •Features new flush-mount terminal adapters that eliminate
the need for spacers ensuring a secure, vibration resistant PART # DESCRIPTION
and direct-path connection 2113-0461 For 79-85 XL

CROSS REFERENCE CHART
ENGINE
DRAG SPECIALTIES YUASA BATTERY HARLEY-DAVIDSON COLD
PART # PART # OEM # CRANKING AMPS LENGTH WIDTH HEIGHT TERMINAL CONFIGURATION
7
1
2113-0461 YTX20H-BS 65991-82B 310 175 mm (6 7 /8”) 87 mm (3 /16”) 156 mm (6 /8”) + -

TRANSMISSION YUASA BATTERIES
& DRIVELINE •The largest motorcycle battery manufacturer in the world
•Over 50 years of engineering expertise ensures high-quality
construction for long and trouble-free service
HIGH-PERFORMANCE AGM MAINTENANCE-FREE BATTERIES
GASKETS •This new generation of maintenance-free batteries delivers higher cranking amps for
& SEALS vehicles that require extra starting power
•Additional cranking amps make these the most powerful batteries on the market
AGM MAINTENANCE-FREE
ELECTRICAL •Special absorbed-glass mat battery eliminates water loss, permitting the battery to be
& LIGHTING permanently sealed once it is filled with acid; Acid Pak included
•Truly the world’s finest “install it and forget it” motorcycle battery Y12N7-4A
CONVENTIONAL
HANDLEBARS, •Built to improve acid flow and resist vibration damage
CONTROLS & •Impact-resistant case and cover
•All batteries are shipped dry
MIRRORS
YUMICRON
•The most powerful lead-acid battery of its size
•Appears as original equipment on more and more big bikes
CABLES YUMICRON CX
•Lead/ calcium battery has 5% to 8% more cranking power than the high-output Yumicron YTX-20BS
•Requires minimal servicing
BATTERY APPLICATIONS CHART
BRAKES DESCRIPTION HIGH-PERFORMANCE AGM MAINTENANCE-FREE AGM MAINTENANCE-FREE CONVENTIONAL YUMICRON YUMICRON CX
For 70-78 XLCH - - Y12N7-4A YB7-A -
For 67-78 XLH - - YHD-12 1 - -
For 79-85 XL/ XLH YTX20H-BS YTX-20BS - YB16-B YB16-B-CX
OIL TANKS, 1 PART #2113-0080 is replacement hardware (5-pk.) for PART #YHD-12.
FILTERS &
GAS TANKS

2113-0247
DASHES 2113-0311
& GAUGES
CHASSIS, RETRO BATTERY CABLES
SUSPENSION, •Available in solid black and red or black with red inflec with red ends
FENDERS •4-gauge cable manufactured with pure electrolytic-grade 36-gauge 2113-0256
& WHEELS tinned copper strands for maximum current transfer and
superior flexibility
1
5
•All manufactured with 6,4 mm ( /4”) and 7,9 mm ( /16”) cable 2113-0317
FLOORBOARDS •Increase starter performance by providing maximum current to
& PEGS starter motor
•Chrome switch housing available separately
•Sold each
•Made in U.S.A.
PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION
HARDWARE
POSITIVE POSITIVE (CONT) NEGATIVE (CONT)
2113-0247 203 mm (8”) Braided retro cable 2113-0310 30,5 cm (12”) Solid red cable 2113-0255 35,5 cm (14”) Braided retro cable
2113-0248 254 mm (10”) Braided retro cable 2113-0311 35,5 cm (14”) Solid red cable 2113-0256 40,5 cm (16”) Braided retro cable
2113-0249 30,5 cm (12”) Braided retro cable 2113-0312 40,5 cm (16”) Solid red cable 2113-0313 203 mm (8”) Solid black cable
2113-0250 35,5 cm (14”) Braided retro cable NEGATIVE 2113-0314 254 mm (10”) Solid black cable
GENERAL 2113-0251 40,5 cm (16”) Braided retro cable 2113-0252 203 mm (8”) Braided retro cable 2113-0315 30,5 cm (12”) Solid black cable
2113-0308 203 mm (8”) Solid red cable 2113-0253 254 mm (10”) Braided retro cable 2113-0316 35,5 cm (14”) Solid black cable
2113-0309 254 mm (10”) Solid red cable 2113-0254 30,5 cm (12”) Braided retro cable 2113-0317 40,5 cm (16”) Solid black cable
