GENERATOR END COVER
GENERATOR COVER •Features die-cast construction with
•Chromed to add a custom look to any generator a smooth chrome finish EXHAUST
PART # DESCRIPTION PART # DESCRIPTION
DS‑373586 For 57-81 XL DS‑325531 For 57-81 XL

GENERATOR CARBURETORS
& AIR FILTERS
POST KIT
•Kit includes two screws,
OEM #2690W; two GENERATOR POLE SHOE SCREW KIT
insulating bushings, OEM #5911; •Kit includes two Parkerized pole shoes with screws ENGINE
two fiber washers, OEM #6186;
two lock washers, OEM #7220 •Made in the U.S.A.
and two nuts, OEM #7634 PART # DESCRIPTION PART # DESCRIPTION
•Made in the U.S.A. 2401‑0605 For 58-78 XL 2401‑0606 For 58-78 XL; repl. OEM #30280-58
TRANSMISSION
& DRIVELINE

GASKETS
& SEALS

ELECTRICAL
& LIGHTING
ALTERNATOR STATOR
•Meets or exceeds OEM specifications and STATOR
features precise construction •Designed for 18A applications HANDLEBARS,
•Uncoated •Made in the U.S.A. CONTROLS &
PART # DESCRIPTION PART # DESCRIPTION MIRRORS
DS‑195093 For L84-85 XL; repl. OEM #29967-84A 2112‑0158 For L84-85 XL; repl. OEM #29967-84A

CABLES

BRAKES
2112-0825 2112-0814 2112-0812 2112-0861
SOLID-STATE REGULATORS 2112-0823 OIL TANKS,
•High-reliability voltage regulators feature rugged aluminum alloy construction and are FILTERS &
available in Drag’s chrome finish GAS TANKS
•All provide accurately regulated voltage under all electrical loads, have no relay contacts to wear or become
maladjusted and are environmentally sealed for protection against moisture and shock
NOTE: 70-75 regulators do not have tach wires. DASHES
FITS MODEL CHROME BLACK OEM # AMPS CHARGING TYPE LEAD LENGTH & GAUGES
For L84-85 XL 2112‑0815 2112‑0825 74523-84A 19 12V 129,5 cm (51”)
For 82-E84 XL w/ generator 2112‑0814 1 2112‑0824 2 74504-82 13 12V 127 mm (5”)
For 78-81 XL, XLCH; 77-78 XLCR 2112‑0813 1 2112‑0823 2 74504-78 10 12V 127 mm (5”) CHASSIS,
For 65-77 XL 2112‑0812 1, 2 2112‑0822 2 All 12V 10 12V N/A SUSPENSION,
For 58-64 XL 2112‑0862 2112‑0861 - 15 6V N/A FENDERS
1 Regulators will work without a battery. & WHEELS
2 Must be hardwired; replaces mechanical regulator OEM #74510-64.
201121-B 201121C FLOORBOARDS
SOLID STATE REGULATORS & PEGS
•High-reliability voltage regulators feature rugged aluminum
alloy construction
•All provide accurately regulated voltage under all electrical loads, have
no relay contacts to wear or become maladjusted and are environmentally sealed for HARDWARE
protection against moisture and shock
NOTE: 70-75 regulators do not have tach wires.
FITS MODEL BLACK CHROME OEM # AMPERAGE LEAD LENGTH
65-77 XL 201104‑B 201104C All 12V 10 N/A
L84-85 XL 201121‑B 201121C 74523-84A 19 129,5 cm (51”) GENERAL
82-E84 XL w/ generator ‑ 201117C 74504-82 13 127 mm (5”)
78-81 XL, XLCH; 77-78 XLCR 201102‑B 201102C 74504-78 10 127 mm (5”)

ALL PART NUMBERS IN BLUE ARE NEW 629
