IRONHEAD XL

2104-0228
SEATS &
SISSY BARS
2104-0229 2104-0230 2104-0231 2104-0232

EXHAUST

CARBURETORS IGNITION WIRE KITS 2104-0253 2104-0254 2104-0255 2104-0256
& AIR FILTERS 2104-0257
•7 mm solid core and 8 mm
suppression core ignition
wire kits
•Fully insulated wires
ENGINE •61 cm L (24”) universal design
•Include spark plug terminals
and boots 2104-0259 2104-0261
•Available in multi-colored retro 2104-0258 2104-0260 2104-0262
TRANSMISSION or standard colors
& DRIVELINE •Sold in pairs
•Made in the U.S.A.
FOR 79-85 XL
PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION
GASKETS RETRO 7 MM SOLID CORE RETRO 8 MM SUPPRESSION CORE (CONT) 8 MM SUPPRESSION CORE (CONT)
& SEALS 2104-0228 Black/ red/ white 2104-0250 Red/ white/ black 2104-0257 Straw
2104-0229 Blue/ red/ black 2104-0251 Yellow/ red/ black 2104-0258 Gold
2104-0230 Red/ white/ black 2104-0252 White/ red/ black 2104-0259 Marigold
2104-0231 Yellow/ red/ black 8 MM SUPPRESSION CORE 2104-0260 Green
ELECTRICAL 2104-0232 White/ red/ black 2104-0253 Black 2104-0261 Beige
& LIGHTING RETRO 8 MM SUPPRESSION CORE 2104-0254 White 2104-0262 Purple
2104-0248 Black/ red/ white 2104-0255 Cardinal
2104-0249 Blue/ red/ black 2104-0256 Maize

HANDLEBARS,
CONTROLS &
MIRRORS
DS-242347
8 MM CUSTOM-COLORED PLUG WIRES
CABLES •Designer plug wire sets come in distinctive, highly visible colors
•Precut and have the plug/ coil boots and terminals
already installed
•Boots and wires are made from extra-high-temperature silicone,
which gives protection up to 315°C (600°F)
BRAKES •Spiro-Pro core provides up to 10 times the conductivity of a standard carbon-core wire
•Low resistance means they run cooler and last 3-4 times longer than carbon-core wires
•Designed for electronic ignitions, but also work great on point types
•Sold in pairs
OIL TANKS, •Made in the U.S.A.
FILTERS & FOR 66-85 XL (90° BOOTS)
GAS TANKS
PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION
DS-242132 Black DS-242347 Purple DS-242349 Blue 2104-0091 Gray w/ black boots
DS-242149 Red DS-242133 Yellow DS-242151 Hot orange
DASHES
& GAUGES
DS-242165
CHASSIS,
SUSPENSION,
FENDERS
& WHEELS

FLOORBOARDS
& PEGS
8,8 MM SPARK PLUG
COPPER CORE XXX 8 MM WIRE SEPARATOR
SPARK PLUG WIRE SETS •Chrome billet T-6
HARDWARE •Copper core wire sets for bikes with aluminum construction
magneto or points type ignitions •Holds wires apart for
CUSTOM 8,8 MM SPARK PLUG WIRE SETS •Rated at SAE CLASS E J2031 with a continuous a cleaner look
•Heavy-duty 8,8 mm silicone wire sets are cut to size and operating temperature of 234°C (450°F) •Sold each
have copper core wire •Made in the U.S.A. •Made in the U.S.A.
GENERAL FITS MODEL YELLOW BLACK PART # DESCRIPTION PART # DESCRIPTION
For 71-E78 XL, XLCH 162074 172074B DS242165 For 71-E78 XL 2107-2578 8,8 mm spark plug
For 58-69 XL, XLCH (w/ magneto) 162075 172075B DS242164 For 58-69 XL w/ a magneto wire separator

616 ALL PART NUMBERS IN BLUE ARE NEW
