IRONHEAD XL

SEATS &
SISSY BARS

EXHAUST

12V IGNITION COILS
CARBURETORS
& AIR FILTERS •Performance, quality and value
•35.000V‑40.000V output 2102‑0215 2102‑0217
•Available with black or red molded body
PART # COLOR DESCRIPTION PART # COLOR DESCRIPTION
2102‑0215 Black 5 ohm/ points ignition/ dual‑fire 2102‑0217 Red 3 ohm/ electronic ignition/ dual‑fire
ENGINE 2102‑0216 Black 4 ohm/ electronic ignition/ dual‑fire 2102‑0308 Black 3 ohm/ electronic ignition/ dual‑fire; repl. OEM #31609‑80

TRANSMISSION
& DRIVELINE

GASKETS 12V IGNITION COILS
& SEALS •Increase peak spark voltage by 20% or more
•Improve starting, stops high‑speed misfires,
increases mileage and overall performance
•30.000V output 2102‑0227 2102‑0220 2102‑0321
ELECTRICAL •50,8 mm (2”) on‑center mounting holes
& LIGHTING PART # DESCRIPTION PART # DESCRIPTION
BLACK CHROME
2102‑0227 5 ohm/ points ignition/ dual‑fire 2102‑0220 5 ohm/ points ignition/ dual‑fire
HANDLEBARS, 2102‑0213 4 ohm/ electronic ignition/ dual‑fire 2102‑0219 4 ohm/ dual‑fire
CONTROLS & 2102‑0228 3 ohm/ electronic ignition/ dual‑fire 2102‑0221 3 ohm/ electronic ignition/ dual‑fire
MIRRORS 2102‑0226 2,4 ohm/ electronic ignition/ single‑fire 2102‑0321 2,4 ohm/ electronic ignition/ single‑fire

CABLES

12V MINI DUAL-FIRE
BRAKES IGNITION COILS
•Improves overall performance including
starting, stops, high‑speed misfires, and
increases mileage 12V BLUE STREAK
®
OIL TANKS, •30.000V output
FILTERS & •Peak spark voltage increases by at least 20% IGNITION COIL
GAS TANKS •Smaller case for easier concealment 2102‑0275 •4,6‑ohm coil for models with point ignition
(approximately 73 mm W x 69,9 mm T x 82,6 mm D •Feature 45.000V+ capacity for superior spark
3
7
(2 /8” x 2 /4” x 3 /4”)) •Heavy‑duty construction for long life
1
•Available with black body •Super‑fast rise time for better response
DASHES •Bolt directly to stock coil bracket
& GAUGES PART # DESCRIPTION •Not for single‑fire ignitions
2102‑0275 3 ohm/ electronic ignition/ dual‑fire; repl. OEM #31614‑83A
2102‑0276 4 ohm/ electronic ignition/ dual fire PART # DESCRIPTION
CHASSIS, 2102‑0277 5 ohm/ points ignition/ dual‑fire DS‑325467 4,6‑ohm coil
SUSPENSION,
FENDERS
& WHEELS
DUAL-FIRE DUAL-TOWER
COMPACT IGNITION COIL
FLOORBOARDS
& PEGS •Three‑ohm 12V coil features a closed‑core
design for greater efficiency
•Produces far greater energy in a small
package than other popular high‑
performance coils 12V IGNITION COIL
HARDWARE •Can be used with any Compu‑Fire •The “industry standard”
ignition system or any ignition that with 35.000V spark energies
calls for a 3‑ohm coil (except Dyna S and second to none
points‑type ignitions) •Designed to work with any Dyna
•Sold each dual‑fire ignition system
GENERAL •Made in the U.S.A. •Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION
DS‑325689 3‑ohm coil DC7‑1 5,0 ohm (black), straight dual output, Std. H‑D style (points) (ea.)

618 ALL PART NUMBERS IN BLUE ARE NEW
