& AIR FILTERS 2-INTO-1 HIGH-EXIT MEGAPHONE SYSTEM
•Chrome system with patented SuperTrapp tuneable disc technology
•Adjust sound levels and powerband by adding or removing 4” external discs
•Includes twelve 4” discs, rebuildable core and packing
ENGINE •Made in the U.S.A.
NOTE: 71-72 models require late 72 or later kick-start arms such as DS-241003 or OEM #33057-72.
PART # DESCRIPTION PART # DESCRIPTION
FOR 71‑84 FX FOR 71‑84 FX (CONT)
TRANSMISSION 828‑77470 Chrome 1800‑1818 Polished
& DRIVELINE

GASKETS
& SEALS
BUILDER’S EXHAUST KIT
•Pre-bent tubing and ready-made flange kit for
ELECTRICAL custom exhaust system fabrication
& LIGHTING •1,75” O.D. 16-guage rolled high-tensile
steel tubing
•Five sets of exhaust flanges included: Ironhead,
HANDLEBARS, Evo, STD, Shovelhead, Panhead
CONTROLS & •Two 3,5” radius U-bends with straights
MIRRORS •Two 5” radius U-bends with straights
•Two 16” long straight sections with flattened tips
•Two 6” long straight sections with Trumpet flares
•Two 45-degree bends with slash cut tips
CABLES PART # DESCRIPTION
1802‑0270 Exhaust kit

BRAKES
EXHAUST FLANGE KIT
3
•Cold-rolled 16-gauge (0,060”) x 1 /4” o.d. high-tensile steel tubing with a raw finish
•Each tube includes two header flanges (one on each end)
OIL TANKS, •Makes building a custom exhaust system much easier
FILTERS & PART # DESCRIPTION
GAS TANKS
1802‑0272 For custom Shovelhead applications

MINI MUFFLERS 1811-2676 1811-2681
DASHES •Mini mufflers slip fit over 1811-2683 1860-0859
& GAUGES the open ends on 1,75”
O.D. custom pipes with
1
CHASSIS, a minimum of 1 /8” of
straight tube at the end
SUSPENSION, •Custom tapered and TIG
FENDERS welded 16-gauge steel
& WHEELS canister with 1,76” I.D. slip
joint end
•TIG welded, stamped steel hanger bracket with Biltwell anvil marking on the back of the mini muffler canisters provide a place to mount
FLOORBOARDS a bracket for custom installations
& PEGS •Gold zinc plated 16-gauge perforated steel baffle tube with stamped and TIG welded end caps
•Fiberglass packing around removable internal baffle assembly provides additional sound muffling and inhibits sparks
•Available in triple chrome plating or matte black high-temperature powdercoating
•Mufflers can be secured on the exhaust tube ends with any standard P-clamps (not included) constructed for this purpose
HARDWARE •Sold each
NOTE: If the current straight pipes feature a removable baffle inside the tube end, it may be necessary to remove the baffle and associated
mounting hardware to facilitate slip fitment of the Biltwell mini muffler over the tube end.
PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION
CHROME BLACK REPLACEMENT BAFFLES
GENERAL 1811‑2676 Stinger (8 /8” L x 2 /16” Dia.) 1811‑2680 Stinger (8 /8” L x 2 /16” Dia.) 1860‑0859 Stinger
5
1
5
1
3
3
1811‑2677 Cannon (8 3 /4” L x 2 /8” Dia.) 1811‑2681 Cannon (8 3 /4” L x 2 /8” Dia.) 1860‑0860 Cannon
1811‑2679 Javelin (9” L x 2 5 /16” W) 1811‑2683 Javelin (9” L x 2 5 /16” W) 1860‑0861 Javelin
