SHOVELHEAD

SEATS & SISSY BAR PAD
SISSY BARS •Complements Le Pera’s seats perfectly
•Top-grade smooth black vinyl covering
•Base plates are powder-coated steel
1
•Pad measures 14 cm W x 20,5 cm H (5 /2” x 8”)
EXHAUST •Made in the U.S.A.
PART # DESCRIPTION
DS‑265452 Sissy bar pad

CARBURETORS
& AIR FILTERS
0822-0044

ENGINE

0807-0009
TRANSMISSION
& DRIVELINE
0822-0097
0822-0100
GASKETS
& SEALS

ELECTRICAL
& LIGHTING
BRACKET-STYLE SISSY BAR PADS
®
•Pads fit all Harley-Davidson and aftermarket bars with welded insert plates 0807-0011
HANDLEBARS, or with no center insert
CONTROLS & •23 cm (9”) pads have an additional threaded center hole for custom mounting
MIRRORS •Premium expanded vinyl construction
•Studded, pillow or vintage styles
•These do not fit touring model sissy bars or bars with die-cast, bolt-in inserts 0822-0098
•Made in the U.S.A.
CABLES PART # DESCRIPTION PART # DESCRIPTION
STUDDED WITH CONCHOS PADS PILLOW PADS (CONT)
0822‑0097 23 cm H x 19 cm W (9” x 7,5”) 0822‑0100 28 cm H x 16,5 cm W (11” x 6,5”)
DS‑265511 23 cm H x 24 cm W (9” x 9,5”) VINTAGE PADS
0807‑0009 23 cm H x 30,5 cm W (9” x 12”) 0822‑0046 15 cm H x 16,5 cm W (6” x 6,5”)
BRAKES DS‑265510 28 cm H x 16,5 cm W (11” x 6,5”) 0822‑0044 23 cm H x 19 cm W (9” x 7,5”)
PILLOW PADS 0807‑0012 23 cm H x 24 cm W (9” x 9,5”)
0807‑0010 15 cm H x 16,5 cm W (6” x 6,5”) 0807‑0011 23 cm H x 30,5 cm W (9” x 12”)
0807‑0013 23 cm H x 19 cm W (9” x 7,5”) 0822‑0098 28 cm H x 16,5 cm W (11” x 6,5”)
OIL TANKS,
FILTERS &
GAS TANKS 1413-0012

DS-110845
DASHES
& GAUGES
1413-0011
CHASSIS,
SUSPENSION, DS-110854
FENDERS
& WHEELS

SADDLEBAG RAIL
FLOORBOARDS
& PEGS DS-110851 SUPPORT BRACKETS
•Heavy-duty steel construction
CHROME SADDLEBAG SUPPORT BRACKETS •15% thicker than stock plates to
prevent breakage
•Chrome-plated steel brackets hold throw-over saddlebags away from the brake caliper •Chrome finish
HARDWARE and swingarm •Mounts with existing hardware
•Fasten to the shock absorber upper studs or fender struts •Sold each
•All necessary mounting hardware included PART # DESCRIPTION
•Sold in pairs
FOR 80‑83 FLT, FLHT
PART # DESCRIPTION 1413‑0011 Left saddlebag rail support
GENERAL DS‑110854 For 66-83 FL bracket; repl. OEM #90718-79C
DS‑110845 For 71-84 FX, 80-84 FXWG; repl. OEM #90584-85 1413‑0012 Right saddlebag rail support
DS‑110851 For 82-83 FXR; repl. OEM #90587-85 bracket; repl. OEM #90720-79C

32 ALL PART NUMBERS IN BLUE ARE NEW
