SHOVELHEAD

SEATS &
SISSY BARS

EXHAUST
SISSY BAR
LUGGAGE RACK ROUND SISSY
•A stylish, convenient place to BARS FOR
secure luggage or support HARDTAIL MODELS CARBURETORS
a travel bag & AIR FILTERS
1
•Fits on most tall, square Drag •Chrome-plated 13 mm ( /2”)
Specialties sissy bars, with holes diameter cold rolled steel
for insertion into the crossbar; •Fits rigid frames with axle plates
mounting holes need to be approximately 25,5 cm (10”) apart ENGINE
44,5 mm to 51 mm (1,75” to 2,0”) •PART #DS-264116 measures DS-264116
on centers approximately 38 cm (15”)
•Can also be mounted to tall, above fender
square OEM sissy bars with •PART #DS-264117 measures TRANSMISSION
mounting holes 44,5 mm (1,75”) approximately 48,5 cm (19”) DS-264117
on centers above fender & DRIVELINE
•Easy to install and remove PART # DESCRIPTION
•Includes mounting hardware PART # DESCRIPTION DS‑264116 For flat fenders
NOTE: Sissy bar sold separately. DS‑720083 Sissy bar luggage rack DS‑264117 For Fat Bob fenders up to 20,5 cm W (8”) GASKETS

& SEALS

ELECTRICAL
1504-0046 & LIGHTING
1504-0047
1504-0045
HANDLEBARS,
CONTROLS &
SISSY BARS AND SIDE PLATES MIRRORS
9
•All sissy bars are constructed from 14,3 mm ( /16”) solid steel
•Side plates are a bolt-on design – no drilling required
•Bars are measured from the first bend to the top of the bar
•Bars and side plates sold separately 1501-0497 CABLES
•Available in chrome
•Made in the U.S.A.
ROUND SISSY BARS
CHROME SIDE CHROME TAPERED BRAKES
APPLICATION PLATES SISSY BAR SIZE BAR WIDTH
For 66-84 FL, FLH 1504‑0046 1501‑0497 25,7 cm (10,1”) 22 cm (8,75”) 1501-0493 1501-0496
For 80-84 FXWG 1504‑0045 1 1501‑0497 25,7 cm (10,1”) 22 cm (8,75”)
OIL TANKS,
1 Plates are notched to fit with OEM turn signals.
SQUARE SISSY BARS FILTERS &
APPLICATION CHROME SIDE PLATES CHROME TALL SISSY BAR SIZE CHROME SHORT SISSY BAR SIZE BAR WIDTH GAS TANKS
For 66-84 FL, FLH 1504‑0046 1501‑0493 37,5 cm (14,75”) 1501‑0494 25,8 cm (10,14”) 22 cm (8,75”)
For 80-84 FXWG 1504‑0045 1 1501‑0493 37,5 cm (14,75”) 1501‑0494 25,8 cm (10,14”) 22 cm (8,75”)
For 82-83 FXR 1504‑0047 1501‑0495 32,5 cm (12,8”) 1501‑0496 25,5 cm (10”) 17 cm (6,69”) DASHES
1 Plates are notched to fit with OEM turn signals. & GAUGES

CHASSIS,
SUSPENSION,
1501-0481
FENDERS
1501-0482 1501-0483 & WHEELS
UNIVERSAL FLOORBOARDS
RIGID FRAME & PEGS
SISSY BAR KITS
•Kits include pre-bent 66 cm (26”) tall sissy bar
loop, two universal mounting tabs, two pre-
bent axle plate mounts, two pre-drilled axle HARDWARE
plate mounts and two /16”-18
5
mounting bungs
•Cut the loop to length and weld
•Available in three styles
•Made in the U.S.A. GENERAL
PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION
1501‑0481 The Classic (pointy top) 1501‑0482 The Rambler (round top) 1501‑0483 The Traveler (square top)

ALL PART NUMBERS IN BLUE ARE NEW 29
