MOUNT KIT FOR SPRING SOLO SEATS
•Kit allows you to mount Drag Specialties Large or Small
Spring Solo Seats with no modifications to the bike
CARBURETORS •No welding required
& AIR FILTERS •Adjustable front mount and complete instructions to ensure accurate installation
•Spring‑mounting studs can be placed at 152 mm or 178 mm (6” or 7”) spacing center‑to‑center
•Include 76,2 mm (3”) springs and all mounting hardware
3
•Bracket is 0,187” steel with black powder‑coat finish; spring mount pins and /8” x 16‑threaded
ENGINE rod for mounting are made of stainless steel; mount centering spacers are made of aluminum
•Seat sold separately
•Made in the U.S.A.
NOTE: Drag Specialties Small Spring Solo Seats will require hinge PART # DESCRIPTION
bracket PART #DS-902013 (sold separately). 0820‑0042 For 66‑84 FX/ FXE/ FXS/ FXB/ FXEF/FL/ FLH, 80‑84 FXWG
TRANSMISSION
& DRIVELINE SPRING SEAT MOUNTS
•Use to install seat springs for spring‑style solo seats
•Available for 25,4 mm (1”) diameter or 32 mm (1,25”) 0820‑0032
diameter frame tubing
GASKETS
& SEALS •Bolt‑on design uses easy‑to‑install bolt‑on spring mounts;
come in a raw finish, ready to be painted
•Weld‑on design requires the mounts to be welded to the frame
•Sold in pairs 0820‑0030
•Made in the U.S.A.
ELECTRICAL
& LIGHTING FOR 66‑84 SHOVELHEAD
PART # DESCRIPTION PART # DESCRIPTION
BOLT‑ON SEAT SPRING MOUNTS WELD‑ON SEAT SPRING MOUNTS
0820‑0032 For 25,4 mm (1”) dia. tubing 0820‑0030 For 25,4 mm (1”) dia. tubing
HANDLEBARS, 0820‑0033 For 32 mm (1,25”) dia. tubing 0820‑0031 For 32 mm (1,25”) dia. tubing
CONTROLS &
MIRRORS

CABLES
REAR SEAT BRACKET WITH RETAINED SCREW
•Chrome‑plated steel bracket features a retained mounting screw
that stays attached with the bracket; /4”‑28 UNF screw with nylon
1
BRAKES SOLO SEAT MOUNTING BRACKET washer (ea.)
•Chromed bracket for Harley rigid frame Big Twin models •Mounting screw has a knurled edge for finger tightening and a hex
•Sold individually socket for wrench tightening
PART # DESCRIPTION PART # DESCRIPTION
OIL TANKS, DS‑902015 For rigid frame Shovelhead DS‑490018 For custom Shovelhead applications
FILTERS &
GAS TANKS
DS‑902004
DS‑902012
DASHES
& GAUGES UNIVERSAL SEAT
HINGE BRACKETS DS‑902014
•Chromed brackets permit seat to flip over
CHASSIS, gas tank for easy access to engine components DS‑902013 BIG TWIN/ UNIVERSAL
SUSPENSION, •Fit most custom rigid Shovelhead applications SEAT BRACKET
FENDERS •Sold individually •Chromed universal bracket lets you mount solo seats to frames
& WHEELS PART # DESCRIPTION without welding
DS‑902012 Round end •Use in conjunction with our universal seat bracket PART #DS‑902013
FLOORBOARDS DS‑902013 Square end PART # DESCRIPTION

& PEGS DS‑902004 Solo seat spring mounting bracket for Big Twin (pr.)
FENDER-MOUNT DS‑902014 Universal front seat bracket (ea.)

SEAT BRACKET
•Mounts Mustang Regal
HARDWARE Touring seats to 77 and
earlier FLH models without SEAT HINGE
a handrail •Stainless steel solo seat hinge
•Seats for 78 and later FLH models mount to •Includes steel weld‑on tab
the stock handrail bracket •Raw finish, ready for polishing or powdercoat
GENERAL •Made in the U.S.A. •Made in the U.S.A.
PART # DESCRIPTION PART # DESCRIPTION
DS‑900399 Fender mount seat bracket 0820‑0043 Solo seat hinge w/ weld‑on tab
