SHOVELHEAD

0806‑0029 SEATS &
0806‑0030
SISSY BARS

EXHAUST

CARBURETORS
& AIR FILTERS

ENGINE

Bottom view 0806‑0031 TRANSMISSION
SHOVELHEAD BOBBER SEATS & DRIVELINE
•All‑leather Bobber‑style seats for custom and rigid Shovelhead applications
•25 mm (1”) thick seats feature steel bases with threaded studs or threaded inserts as listed
PART # DESCRIPTION
FOR CUSTOM/ RIGID SHOVELHEAD GASKETS
1
5
0806‑0029 28 cm W x 33 cm L (11” x 13”); /16‑18 threaded studs on 18,5 cm center (7 /4”) & SEALS
0806‑0030 30,5 cm W x 33 cm L (12” x 13”); 5 /16‑18 threaded studs on 18,5 cm center (7 /4”)
1
0806‑0031 30,5 cm W x 38 cm L (12” x 15”); 1 /4‑20 threaded inserts on 16,5 cm center (6 /2”)
1

ELECTRICAL
& LIGHTING
HANDLEBARS,
0806‑0043 CONTROLS &
0806‑0046 MIRRORS

CABLES

Bottom view Bottom view
BRAKES
SPRING SOLO SEAT BASES
•16‑gauge steel construction with 25,4 mm x 4,8 mm (1” x /16”) welded‑in center bar
3
•Include perimeter rubber channel
•Painted black finish OIL TANKS,
PART # DESCRIPTION FILTERS &
FOR CUSTOM/ RIGID SHOVELHEAD APPLICATIONS GAS TANKS
1
0806‑0043 Small base w/ rear studs 152 mm (6”) on center and measures 32 cm L x 23 cm W (12 /2” x 9”) (includes hinge)
0806‑0046 Large base w/ rear studs 178 mm (7”) on center and measures 40,5 cm L x 33 cm W (16 1 /4” x 13”) (does not include hinge)

DASHES
DS‑902171 & GAUGES
CHASSIS,
SUSPENSION,
DS‑905564 FENDERS
& WHEELS

FLOORBOARDS
& PEGS
PASSENGER PADS WITH ARMRESTS
•Original‑style wrap‑around backrests with armrests that
are 51 mm (2”) longer than OEM match Mustang or later‑model
stock Harley‑Davidson seats HARDWARE
•Covering made of highest‑quality expanded vinyl
•Complete kit includes rubber mounts to fit models with King Tour Paks
•Made in the U.S.A.
NOTE: Requires some drilling.
FOR 80‑83 FLT/ FLHT W/ KING TOUR PAKS GENERAL
PART # DESCRIPTION PART # DESCRIPTION
DS‑902171 Regal style w/ armrests DS‑905564 Regal style w/ armrests and studs

ALL PART NUMBERS IN BLUE ARE NEW 23
