Page 391 - Tires 2017

GENERAL, METRIC SERVICE/MAINTENANCE TOOLS

STREET
TIRES

DRAG/
V-TWIN TIRES

SCOOTER
QRS CLUTCH TIRES
SPRING COMPRESSION TOOL COMPRESSION TOOL
FOR ARCTIC CAT DRIVEN CLUTCH •Simple and effective way to compress the
12‑15 (EXCEPT DIAMOND DRIVE secondary for helix and spring removal on all
MODELS), BOSS MODELS 16‑17, AND 08-17 Ski-Doo QRS clutches without removing OFFROAD
ALL SKI‑DOO TRA DRIVE AND REAR UNIVERSAL the entire jackshaft TIRES
DRIVEN CLUTCHES SPRING COMPRESSOR •Uses a safe, rubber-style expandable bushing for
internal threaded machines
•Change drive or driven springs easily and safely •Removes all primary and secondary clutch springs •Can be used on both inner thread and outer
•Designed to be used in a vise or mounted to •Removes Arctic Cat Diamond Drive Springs thread secondary
a bench •Directly bolts to a bench or fits in any standard vise •Can install in seconds; no threading required ATV/UTV
DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION PART # TIRES &
Spring compression tool 20‑143 Universal spring compressor 3803‑0050 QRS clutch compression tool 3803‑0085 WHEELS

TUBES &
ACCESSORIES

SHOP EQUIPMENT
TRA CLUTCH HOLDER & STANDS
SPRING CHANGE TOOL •Holds all 2003 and newer TRA primary
clutches, TRA3, TRA5 and TRA7
•Recommended for changing springs in our Team •Made from high tensile steel and corrosion finish, high-strength Delrin to GENERAL,
Rapid Reaction™ snowmobile secondary clutch protect the clutch from scratching METRIC SERVICE/
DESCRIPTION PART # DESCRIPTION PART # MAINTENANCE
Spring change tool 930001 TRA clutch holder 3803‑0052 TOOLS

DRAG/
V-TWIN TOOLS

CLUTCH HOLDING TOOLS 3803‑0047 3803‑0048 CHEMICALS &
LUBRICANTS
•Precision laser-cut design with a zinc coating
•PVC-coated handle prevents scratches and is
more comfortable to use 3803‑0046
FITS MODEL PART # CLEANERS,
ARCTIC CAT POLISHES &
Arctic Cat 6-tower and 9-tower, Comet 100C, 101C, 102C, 108C, 108EXP (OEM #0644-136) 3803‑0046
POLARIS PAINTS
P85 and P90 primary clutches 3803‑0046
SKI‑DOO
TRA primary clutches (OEM #529-0064-00) 3803‑0047
YAMAHA TRANSPORT
YPZ, YXR and YVXC primary clutches (OEM #YS-41279) 3803‑0048 & TRAILER

CLUTCH HOLDERS MERCHANDISING
•Used to hold the stationary clutch sheave while assembling/ disassembling the clutch
•Must-have to go with our jam nut and spider tool 725‑180
•Can be bench-mounted or clamped in a vice 725‑181
•Available for Arctic Cat, Comet and Polaris clutch applications
FITS MODEL PART # INDEX
Arctco 102C, 108C, Arctic Cat 9-tower and 6-tower (except 800/ 900 twins), Comet 100C, 101C, 102C, 108C and 108EXP; Polaris P85 and P90 (30mm shaft) 725‑180
Arctic Cat models 02 and later 800/ 900 Twins, 03 and later 600/ 700/ 800/ 1000 laydown Twins (33 mm tapered shaft) 725‑181

391
All part numbers in BOLD MAGENTA are new this year.
