IRONHEAD XL

SEATS &
SISSY BARS

EXHAUST

CARBURETORS
& AIR FILTERS

0203-0413 0203-0412
ENGINE 0203-0415

DS-380155
TRANSMISSION
& DRIVELINE

GASKETS
& SEALS
REPLACEMENT
LACED WHEELS
•40-spoke wheels feature chrome
ELECTRICAL steel rims, chrome spokes and 0204-0374
& LIGHTING chrome steel hubs (unless noted)
•Fully assembled and trued with
bearings installed and end play set
HANDLEBARS, •Available in most applications 0204-0370 0204-0373
CONTROLS & •Uses OEM mounting hardware
MIRRORS PART # DESCRIPTION PART # DESCRIPTION
FRONT WHEELS REAR WHEELS (CONT)
0203‑0413 1, 3 19” x 2.5” for 84-85 XL; repl. OEM #43312-84 0204‑0374 2 16” x 3” for 79-81 XL; repl. OEM #43720-81
DS‑380155 1, 3 19” x 2.5” for 78-83 XL (dual disc); repl. OEM #43341-78 0204‑0373 2 16” x 3” for 57-78 XL/K
CABLES 0203‑0412 1, 3 21” x 2.15” for 84-85 XL (single/ dual disc); repl. OEM #43557-87 1 Has a polished and chrome-plated billet aluminum hub.
0203‑0415 1, 3 21” x 2.15” for 78-83 XL 2 SRV stem style.
REAR WHEELS 3 CMV stem style.
0204‑0370 4 16” x 3” for 82-85 XL; repl. OEM #40951-82 4 SMV stem style.

BRAKES

OIL TANKS,
FILTERS &
GAS TANKS

DASHES
& GAUGES

CHASSIS,
SUSPENSION,
FENDERS
& WHEELS
POWDERCOATED 40-SPOKE
WHEEL ASSEMBLIES
FLOORBOARDS •Affordable 40-spoke assemblies look great on
& PEGS “old school” bikes
•Feature chrome spokes and a chrome steel
hub with custom powdercoated hubcaps to
hide the mounting hardware
HARDWARE •Designed for applications with /4” Timken bearings
3
•Bearings are pre-set at the factory and ready to install
FRONT WHEELS REAR WHEELS
PART # DESCRIPTION PART # DESCRIPTION
FOR 78‑83 XL AND PAUGHCO WIDE SPRINGERS FOR 82‑85 XL
GENERAL (WHEN USING A SINGLE DISC BRAKE) 0204‑0425 Black, 16” x 3.00”
0203‑0537 Black, 21” x 2.15” 0204‑0426 Red, 16” x 3.00”
0203‑0538 Red, 21” x 2.15”

738 ALL PART NUMBERS IN BLUE ARE NEW
